Pavone Systems DAT 700 Technical Manual page 40

MODBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT11)
MODBUS
Holding Register
Address
0001 Status Register
0002 No. decimal digits of weight
0003 Gross weight (MSB)
0004 Gross weight (LSB)
0005 Net weight (MSB)
0006 Net weight (LSB)
0007 Peak (MSB)
0008 Peak (LSB)
0009 Logic inputs
0010 Logic outputs
0021 Threshold 1 (MSB)
0022 Threshold 1 (LSB)
0023 Threshold 2 (MSB)
0024 Threshold 2 (LSB)
0051 Data Register (MSB)
0052 Data Register (LSB)
0053 Command Register
0100 Load cell capacity (MSB)
0101 Load cell capacity (LSB)
0102 Load cell sensitivity
0103 Weight division value
0200 Weight filter factor
0201 Weight stability factor
0202 Auto zero threshold
0203 Zero tracking factor
0204 Zero band
0205 Delta weight
0301 Threshold 1 operation mode
0302 Threshold 1 hysteresis
0303 Threshold 2 operation mode
0304 Threshold 2 hysteresis
0401 Analog scale bottom (MSB)
0402 Analog scale bottom (LSB)
0403 Analog output func. mode
0404 Analog Output Range
0405 Analog output value
(*) These registers can be changed only in case of FREE operation or in case of METRIC operation with calibration jumper
enabled.
pag. 40
R/W
R See related table
R
R Value signed in the complement of 2.
R
R Value signed in the complement of 2.
R
R Value signed in the complement of 2.
R
R DAT 700 / ANA only. In the other versions it is always 0.
R/W
Writing outputs only if thresholds are programmed to 0
R/W Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
W Write before or with the same query as Command Register
W
W See related table
R/W
R/W
R/W
R/W See related table
R/W
R/W
R/W
R/W
R/W
R/W Not used, fixed at 20 divisions
R/W See related table, Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
R/W See related table, Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
R/W Used only for DAT 700 / ANA
R/W 0 = gross, 1 = net, 2 = peak. Used only for DAT 700 / ANA
R/W 0 = 0-20 mA, 1 = 4-20 mA, 2 = 0-10 V, 3 = 0-5 V
W 0 = zero offset, 65535 = analog scale bottom
