Pavone Systems DAT 700 Technical Manual page 19

SERIAL PORTS SETTINGS – ETHERCAT CONFIGURATION
Sub Message
Menu
T.SER.
C1 M O D .
C1PROT.
C1BAUD.
COMM. P
C1FORM.
EN. FBUS.
INP.REG.
OUT.REG.
In case of ETHERCAT fieldbus: devices should be connected with ring type (as per EtherCAT specification),
I
refer to the installation manual for the use of INPUT ports and OUTPUT.
Four different XML configuration files are provided:
"Hilscher NIC 52-RE ECS V4.2.X 32 Byte.xml" (input area 32 32 bytes, output area 32 bytes).
•
"Hilscher NIC 52-RE ECS V4.2.X 64 Byte.xml" (input area 64 bytes, output area 64 bytes).
•
"Hilscher NIC 52-RE ECS V4.2.X 96 Byte.xml" (input area 96 bytes, output area 96 bytes).
•
"Hilscher NIC 52-RE ECS V4.2.X 128 Byte.xml" (input area 128 bytes, output area 128 bytes).
•
The file that corresponds to the size of the input and output areas selected in the instrument must be
imported into the PLC (for example, if IMP.REG. =128 and OUT.REG. =128 is set in the instrument, the file
"Hilscher NIC 52-RE ECS V4.2.X 128 Byte.xml" must be imported into the PLC). Multiple files with different
sizes can be im- ported, but in this case, it will not be possible to perform the automatic research and
configuration function for devices on the network.
DAT700 Instrument User Manual
Name
Select whether similar operation
Serial Mode
to DAT1400 or DAT100
RS232 Output Transmitted value selection with
mode RS232 output.
RS232
Select communication type for
Communication
RS232 port.
protocol
Baud rate selection for the
RS232 Baud
rate
In case of SLAVE protocol, 7-bit
RS232 Frame
data format (E-7-1 and O-7-1)
cannot be selected.
Enabling EtherCAT fieldbus, if
OFF any error messages
Fieldbus
regarding EtherCAT
Enabling
communication are never
Input area size for EtherCAT
Input Area
fieldbus (value expressed in
Size
Output area size for EtherCAT
Output Area
fieldbus (value expressed in
Size
Description
RS232 port.
Frame type.
displayed
Bytes).
Bytes).
Default
Type
Sel. D1400 D1400 / DAT11
Sel. NET NET / GROSS /
None / Tx continuous
Sel. None
Automatic Slave /
1200 / 2400 / 4800
9600 / 19200 / 38400
Sel. 9600
57600 / 115200
N-8-1 / N-8-2 / E-7-2
Sel. N-8-1
E-8-1 / O-7-2 / O-8-1
Sel. OFF
Sel. 128 32 / 64 / 96 / 128
Sel. 128 32 / 64 / 96 / 128
Range
PEAK
On demand /
Printer
OFF
ON
pag. 19
