Pavone Systems DAT 700 Technical Manual page 4

6-digit DISPLAY
Normally the display shows the measured net weight. According to the various programming procedures,
the display is used for programming parameters to be entered into memory, i.e., messages that indicate
the type of operation being performed and thus assist the operator in managing and programming the
instrument.
STAND-BY FUNCTION
The display screen can take a stand-by state, during which time the screen brightness is reduced and the
keypad is locked. All other functions of the instrument are active and functioning.
See the section on activating/deactivating the stand-by state.
The instrument is programmed and controlled through the keyboard consisting of 3 mechanical keys, with
the following function:
pag. 4
INSTRUMENT FRONT PANEL
KEYBOARD USE
Symbol
Short press on the single key.
Long press on the single key.
Description
DAT700 Instrument User Manual
