MODBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT1400)
The instrument parameters that can be read or programmed through the available communication interfaces on the
instrument, depending on the hardware configuration, are listed in the following table.
R-type registers are the readable ones while W-type registers are the writable ones.
In case of Modbus TCP protocol, the address of the instrument ("Unit Identifier" field) must always be FFh. If a
fieldbus (other than Modbus) is used, only R or R/W registers will be present in the input area, and only W or
R/W registers will be present in the output area.
The registers are 16 bits in size.
MODBUS
Holding Register
Address
0001 Status Register
0002 Gross weight (MSW)
0003 Gross weight (LSW)
0004 Net weight (MSW)
0005 Net weight (LSW)
0006 Peak (MSW)
0007 Peak (LSW)
0008 Digital Inputs
0009 Digital Outputs
0101 Net weighed weight (MSW)
0102 Net weighed weight (LSW)
0103 Weighing Code (MSW)
0104 Weighing Code (LSW)
0201 Set-Point 1 (MSW)
0202 Set-Point 1 (LSW)
0203 Set-Point 2 (MSW)
0204 Set-Point 2 (LSW)
0501 Data Register (MSW)
0502 Data Register (LSW)
0503 Command Register
1001 Stand-By Function
1002 Keyboard Lock Function
1003 Password Function
1004 Peak Function
1005 Data-Logger Function
1006 Data-Logger Trigger
1007 Data-Logger Frequency
DAT700 Instrument User Manual
R/W
See related table
R
INT. Value - Most significant word
R
R INT. Value- Least significant word
R INT. Value- Most significant word
R INT. Value- Least significant word
R INT. Value- Most significant word
INT. Value- Least significant word
R
R
See related table
R
R INT. Value- Most significant word
R INT. Value- Least significant word
R INT. Value- Most significant word
R INT. Value- Least significant word
R/W INT. Value- Most significant word
R/W INT. Value- Least significant word
R/W INT. Value- Most significant word
R/W INT. Value- Least significant word
W INT. Value- Most significant word (See related table)
W INT. Value- Least significant word (See related table)
W See related table
R/W INT. Value
R/W See related table
R/W INT. Value
R/W See correspondence on page10
R/W See correspondence on page10
R/W See correspondence on page10
R/W See correspondence on page10
Notes
