Menu Message
H1 R E S .
PSUPPL.
TEST
RS 232
RS 485
MEMORY
TEST FUNCTIONS - RS232 AND RS485
The test consists of transmitting the string received from the relevant serial line (echo) and displaying the number of strings
received and the number of characters received in the last string.
Upon exit setup menu, if parameter changes have been made, the
PRG
This function allows downloading or uploading of the instrument's setup memory
Download function: instrument setup parameters are stored in a file.
•
Upload function: the instrument is configured with setup parameters read from a file.
•
To use these functions, it is necessary to activate the relevant procedure ("receive file" or "transmit
file") in the TESTER 1008 tool.
I
The handheld TESTER 1008 must be connected to the serial COM1 (Rs232) of the instrument.
DAT700 Instrument User Manual
PROGRAMMING MENU
Name
Resolution x10
Supply voltage
RS232 Test
RS485 Test
Alibi memory Test
SETUP MEMORY UPLOAD/DOWNLOAD
Description
Weight display with 10 times higher resolution than the set
resolution
Display of correct voltage (RIGHT, LOW, HIGH)
Transmission and reception test
(
See specific description
Transmission and reception test
(
See specific description
Fiscal memory test
00C= 00
STORE
message is displayed, to confirm with
)
)
:
pag. 31
Tipo
Vis.
Vis.
Test
Test
Test
