Pavone Systems DAT 700 Technical Manual page 16

I
Access to this menu is allowed only in case of FREE operation or in case of password access by
authorized personnel (in case of METRIC operation)
Sub Message
Menu
USE
MOT1ON
AUTO-0
PARAM.
0-TRAC.
0-BAND.
0-ALL.
Sub Message
Menu
F1ELDB.
pag. 16
PARAMETER MENU
Name Description
Selection of instrument
operation. When changing from
Instrument FREE operation to METRIC
operation, password
Operation
authentication of authorized
personnel is required to confirm
Weight stability settable with 5
different ranges: 0 - Weight
Weight
always stable
Stability
4 - Stable weight with the highest
This function performs an
automatic zero calibration when
Auto-zero
the instrument is turned on, only
on start-up
if the detected weight stabilizes
within the set threshold. To
disable the function, set 0.
The function is to perform a zero
calibration automatically when
the weight undergoes a slow
change over time, determined by
Zero tracking
this parameter.
To disable the function set none.
The maximum weight that can
be zeroed by this function is 2%
of the system capacity.
Resettable Maximum number of resettable
Divisions divisions with key >0< or input
If enabled when the zero key is
Enable pressed for 5 seconds or the zero
zero input is closed for 5 seconds, zero
calibration calibration is performed.
FIELDBUS MENU
Name Description
Selects the
externally
connected fieldbus.
Depending on this
Fieldbus
selection, the next
serial port menu
will be modified.
Type
the setting.
Com.
accuracy.
Com.
Com
Type
Default Range
Free [0]
Sel. Free
Trade [1]
2
0
0—Capacity
None [0]
0.5 div./sec [1]
1 div./sec [2]
Sel. none
2 div./sec [3]
3 div./sec [4]
100 0—200
Sel. OFF OFF/ON
Defaul Range
t
RS485 [0]
PROFIB [1]
PROFNT [2]
DEVNET [3]
Sel. none
CANOP [4]
ETHERN [5]
ETH-IP [6]
ETHCAT [7]
DAT700 Instrument User Manual
Ind.Fi
eldbus
0 ÷ 4 1303
1304
(MSB)
1305
(LSB)
1306
1307
Ind.Fi
eldbus
9004
