Pavone Systems DAT 700 Technical Manual page 20

SERIAL PORTS SETTINGS – PROFIBUS CONFIGURATION
Sub
Message
Menu
T.SER.
C1 M O D .
C1PROT.
C1BAUD.
COMM. P
C1FORM.
EN. FBUS.
ADDR.PR.
INP.REG.
OUT.REG.
If the module used is PROFIBUS HMS, the configuration file "hms_1810.gsd" must be provided to the
customer.
If the module mounted is PROFIBUS X90, the configuration file "hil_x90.gsd" must be provided to the
customer.
pag. 20
Name
Select whether similar
Serial Mode
operation to DAT1400 or
DAT100
RS232 Output Transmitted value selection
mode
RS232
Select communication type for
Communication
RS232 port
protocol
Baud rate selection for the
RS232 Baud rate
In case of SLAVE protocol, 7-
RS232 Frame
bit data format (E-7-1 and O-7-
1) cannot be selected.
Profibus fieldbus enabling, if
OFF any error messages
Fieldbus
Enabling
communication are never
Profibus Profibus protocol
address
Input area size for Profibus
Input Area Size
fieldbus (value expressed in
Output area size for Profibus
Output Area
fieldbus (value expressed in
Size
Description
with RS232 output.
RS232 port.
Frame type.
regarding Profibus
displayed
communication address
Bytes).
Bytes).
Type
Default
Sel. D1400
Sel. NET
Sel. None
Sel. 9600
Sel. N-8-1
Sel. OFF
Com.
1
Sel. 128
Sel. 128
DAT700 Instrument User Manual
Range
D1400
DAT11
NET
GROSS
PEAK
None Tx
continuous
On demand
Automatic
Slave
Printer
1200
2400
4800
9600
19200
38400
57600
115200
N-8-1
N-8-2
E-7-2
E-8-1
O-7-2
O-8-1
OFF
ON
1 ÷ 126
32
64
96
128
32
64
96
128
