FIELDBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT1400)
Register
OUTPUT AREA REGISTER
address
28 Scale Bottom (MSB) (*)
29 Scale Bottom (LSB) (*)
30 Weight stability (*)
31 Autozero on start-up (MSB) (*)
32 Autozero on start-up (LSB) (*)
33 Zero tracking (*)
34 Resettable Divisions (tasto >0<) (LSB)
(*)
35 Input 1 function
36 Input 2 function
37 Output 1 mode—Function
38 Output 1 mode—Logic
39 Output 1 mode —Polarity
40 Output 1 mode —Stability
41 Output 1 hysteresis
42 Output 1 timing
43 Output 1 delay
44 Output 2 mode—Function
45 Output 2 mode —Logic
46 Output 2 mode —Polarity
47 Output 2 mode —Stability
48 Output 2 hysteresis
49 Output 2 timing
50 Output 2 delay
51 Fixed Analog Tare (MSB)
52 Fixed Analog Tare (LSB)
53 Analog Scale Bottom (MSB)
54 Analog Scale Bottom (LSB)
55 Analog Output Mode
56 Analog Output Range
(*) These registers can be changed only in case of FREE operation or in case of METRIC operation with calibration jumper
enabled.
DAT700 Instrument User Manual
INT value - Most Significant Word
INT value - Least Significant Word
See correspondence on page 13
INT value - Most Significant Word
INT value - Least Significant Word
See correspondence on page 13
INT value
See correspondence on page 14
See correspondence on page 14
See correspondence on page 14
See correspondence on page 14
See correspondence on page 14
See correspondence on page 14
INT value
INT value
INT value
See correspondence on page 14
See correspondence on page 14
See correspondence on page 14
See correspondence on page 14
INT value
INT value
INT value
INT value - Most Significant Word
INT value - Least Significant Word
INT value - Most Significant Word
INT value - Least Significant Word
See correspondence on page 16
See correspondence on page 16
