FIELDBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT1400)
The following table lists the output area registers (written by the master and acquired by the instrument) common
to all PROFINET, ETHERCAT, ETHERNET/IP, PROFIBUS and DEVICENET fieldbuses.
The registers are 16 bits in size. The registers written by the master in the output area, are read by the instrument with
a maximum frequency of 125 Hz (80 Hz in case of PROFIBUS fieldbus).
The size of the output area configured in the fieldbus master must match the size configured in the instrument.
Register
OUTPUT AREA REGISTER
address
0 Command Register
1 Data Register (MSB)
2 Data Register (LSB)
3 Monitor register
4 Set-Point 1 (MSB)
5 Set-Point 1 (LSB)
6 Set-Point 2 (MSB)
7 Set-Point 2 (LSB)
8 Load cell capacity (MSB) (*)
9 Load cell capacity (LSB) (*)
10 Load cell sensitivity (*)
11 Weight division value (*)
12 Decimals (*)
13 Fixed Tare (MSB) (*)
14 Fixed Tare (LSB) (*)
15 Stand-By Function
16 Keyboard Lock Function
17 Password Function
18 Peak Function
19 Data-Logger Function
20 Data-Logger Trigger
21 Data-Logger Frequency
22 Filter factor
23 Output rate ADC
24 Number of readings per average
25 Monotony Time
26 Oscillations Time
27 Oscillations Range
pag. 44
See related table
INT Value - Most Significant Word (See related table)
INT Value - Least Significant Word (See related table)
This value is copied to the equivalent input area register
INT Value - Most Significant Word
INT Value - Least Significant Word
INT Value - Most Significant Word (See related table)
INT Value - Least Significant Word
INT Value - Most Significant Word
INT Value - Least Significant Word
INT Value
See related table
INT Value - Most Significant Word
INT Value - Least Significant Word
INT Value
See related table
INT Value
See correspondence on page 10
See correspondence on page 10
See correspondence on page 10
See correspondence on page 10
See correspondence on page 13
See correspondence on page 13
INT Value
INT Value
INT Value
INT Value
Notes
