MODBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT1400)
MODBUS
Holding Register
Address
1301 Scale Bottom (MSW) (*)
1302 Scale Bottom (LSW) (*)
1303 Weight stability (*)
1304 Auto zero on startup (MSW) (*)
1305 Auto zero on startup (LSW) (*)
1306 Zero tracking (*)
1307 Resettable Divisions (*)
1308 Resettable Divisions (*)
1401 Input 1 function
1402 Input 2 function
1403 Output 1 mode —Function
1404 Output 1 mode —Logic
1405 Output 1 mode —Polarity
1406 Output 1 mode —Stability
1407 Output 1 hysteresis
1408 Output 1 timing
1409 Output 1 delay
1410 Output 2 mode —Function
1411 Output 2 mode —Logic
1412 Output 2 mode —Polarity
1413 Output 2 mode —Stability
1414 Output 2 hysteresis
1415 Output 2 timing
1416 Output 2 delay
1501 Analog Tare (MSW)
1502 Analog Tare (LSW)
1503 Analog Scale Bottom (MSW)
1504 Analog Scale Bottom (LSW)
1505 Analog Output Mode
1506 Analog Output Range
1507 Analog zero adjustment
1508 Analog scale bottom adjustment
2000 Monitor register
2100 Monitor register
(*) These registers can be changed only in case of FREE operation or in case of METRIC operation with calibration jumper
enabled.
DAT700 Instrument User Manual
R/W
R/W INT. Value - Most significant word
R/W INT. Value- Least significant word
R/W See correspondence on page 13
R/W INT. Value- Most significant word
R/W INT. Value- Least significant word
R/W See correspondence on page 13
R/W INT. Value- Most significant word
R/W INT. Value- Least significant word
R/W See correspondence on page 14
R/W See correspondence on page 14
R/W See correspondence on page 14
R/W See correspondence on page 14
R/W See correspondence on page 14
R/W See correspondence on page 14
R/W INT. Value
R/W INT. Value
R/W INT. Value
R/W See correspondence on page14
R/W See correspondence on page14
R/W See correspondence on page14
R/W See correspondence on page14
R/W INT. Value
R/W INT. Value
R/W INT. Value
R/W INT. Value- Most significant word
R/W INT. Value- Least significant word
R/W INT. Value- Most significant word
R/W INT. Value- Least significant word
R/W See correspondence on page16
R/W See correspondence on page16
INT. Value Zero points analog output, to terminate the adjustment
R/W procedure, it is necessary to send the command save data to
permanent memory in the command register.
INT. Value Scale bottom points analog output, to finish the
R/W adjustment procedure, it is necessary to send the command save
data in permanent memory in the command register.
The programmed value is automatically copied to Monitor Register
W
(2100).
R
