FIELDBUS COMMUNICATION PROTOCOLS (SERIAL TYPE = DAT11)
The following table lists the input area registers (produced by the instrument and read by the master) common to all
PROFINET, ETHERCAT, ETHERNET/IP, PROFIBUS and DEVICENET fieldbuses.
The registers are 16 bits in size. The input area is updated with a maximum frequency of 125 Hz (80 Hz in case of
PROFIBUS fieldbus). The size of the input area configured in the fieldbus master must match the size configured
in the instrument.
Register
INPUT AREA REGISTER
address
1 Status Register
2 Gross weight (MSB)
3 Gross weight (LSB)
4 Net weight (MSB)
5 Net weight (LSB)
6 Peak (MSB)
7 Peak (LSB)
8 Load cell capacity (MSB)
9 Load cell capacity (LSB)
10 Load cell sensitivity
11 Weight division value
12 Weight filter factor
13 Weight stability factor
14 Autozero threshold
15 Autozero threshold
16 Zero tracking factor
17 Zero band
18 Delta weight
19 Monitor register
pag. 46
See related table.
Int 16 bits
Int 16 bits
Int 16 bits
Int 16 bits
Int 16 bits
Int 16 bits.
See related table.
Int 16 bits
Int 16 bits
Notes
