Ranger XP1000
RG4-Q3V1
2018-Up Polaris Ranger XP1000
3 Speaker RGB LED Audio Kit
Phase 3 with JVC MR1
Advertisement
Related Manuals for SSV Works RG4-Q3V1
Summary of Contents for SSV Works RG4-Q3V1
- Page 1 RG4-Q3V1 2018-Up Polaris Ranger XP1000 3 Speaker RGB LED Audio Kit SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030 Phase 3 with JVC MR1 www.SSVworks.com Phone: 818-991-1778 Fax: 866-293-6751 Ranger XP1000 Panels and Dash Disassembly Amp Tray...
- Page 2 WIRING DIAGRAM OF COMPLETE KIT Figure 1 Figure 1 is designed to show the installer a reference overview of the complete 3 speaker RGB LED wiring diagram. Each installation section will have its own detailed wiring diagram. Description Part # Bluetooth Media Receiver w/ 2.7”...
- Page 3 All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. instructions completely before All SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. installation to avoid possible injury, or Labor for replacement of defective components is not covered.
- Page 4 G. Extract push pins exposed from cup holder removal. H. Extract push pins exposed from gauge cluster removal. I. Extract push pins located above driver and passenger side cup J. Lift to remove the dash. holders. K. Extract push pins located beneath 12v sockets. L.
- Page 5 WARRANTY INFORMATION: Please read and understand these All SSV Works enclosures are covered by a limited lifetime warranty against defects in material instructions completely before or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against installation to avoid possible injury, or defects in material or workmanship.
- Page 6 A. Unscrew the two (2) torx screws connecting the dash bracket at the rear B. Move the factory wiring to the rear of the dash cavity. Place the of the dash cavity. Remove the under dash bracket. RG4 Amp mounting plate in the former location of the factory NOTE: IT WILL NOT BE RE-INSTALLED.
- Page 7 DASH KIT ASSEMBLY PARTS LIST PARTS LIST IMAGES 1. DMR1 Dash Kit x1 2. JVC MR1 Headunit and 4. B-H1752 Pulse 3. M6 x 1.0 Screws 4. U-Clips x2 5. Push Pins x2 Trim Ring Power/Ground x2 (T-30 torx) Harness JVC MR1 Media Player, base mounting plate, trim ring and dash screws included with kit compatible head INSTALLATION NOTES units not included with RG4-DMR1.
- Page 8 C. Using a panel removal tool gently lift the existing plastic panel on the center dash support. Install the two (2) supplied U-Nut clips by sliding them onto the bottom of the center dash panel support and align holes as needed. E.
- Page 9 J. Secure the backside of the R1 with (2) push pins (circled in blue). I. Secure the MR1 with the (4) M3.5 screws provided with the MR1. Fasten (2) M6 T30 screws and washers into each front hole (circled in pink). K.
- Page 10 WARRANTY INFORMATION: All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. Labor for replacement of defective components is not covered. Contact SSV Works for further warranty information.
- Page 11 RGB LED CONTROLLER COMMAND CENTER WIRING DIAGRAM Detail Description Description Part # RGB LED Controller Rocker Switch for LIT-CC B-H2367 Connect RGB LED Rocker Switch to LIT-CC LIT-CC RGB LED Controller Command Center 230-LIT-CC Connect Outputs to Front Speaker and Rear Extension Harnesses LIT-CC Power Harness Connect LIT-CC Power Harness to Battery or ACC Battery...
- Page 12 SUBWOOFER ENCLOSURE INSTALLATION TOOLS NEEDED FOR INSTALLATION - Panel Removal Tool - Drill - 13/64” Drill Bit - T-30 & T-40 Torx Driver - 4mm Allen Key B. Flip up passenger seat and remove center tray to access A. Align bracket A’s holes with the dimples/recess’ circled in pink on the bottom of the enclosure.
- Page 13 H. Once marked, remove the enclosure. Using a I. . Re-install the sub-enclosure. Secure the front G. With the brackets seated into one another, 13/64” drill bit, drill pilot holes at your marked mounting tabs with the kit provide T30 torx use the front mounting tabs as a template points.
- Page 14 FRONT RGB LED KICK PODS PARTS LIST PARTS LIST IMAGES 1. RG4-F65V Enclosures 2. Enclosure Brackets x 4 3. M6 x 16mm Screws 4. M6 Washers x 8 (small) 4. M6 Washers x 2 (large) (1 pair) x 10 RGB LED FRONT KICK PODS ASSEMBLY TOOLS NEEDED FOR INSTALLATION - T-30 Torx Driver - Panel Removal Tool...
- Page 15 E. Place the speaker pod in location and resecure the factory screws through the pod brackets on the front and underneath the dash. P. From the inside-top of the dash, secure the top mounting M6 screw and large washer to the pod through the smaller hole next to the routed speaker wire (figure F1).
- Page 16 CONNECTING POWER & GROUND CABLE TO BATTERY Battery Terminal Cable Power Wire Break Break off tab off tab A1. Remove the bottom cover of the fuse holder A2. Extract both fuse holder screws and fasten A3. Attach both the Power Wire and Battery by extracting the 2 screws.
-
Page 17: Amp Wiring Diagram
Install fuseholder between B-H1587 & battery terminal cable. Connect ground ring terminal to chassis ground. THIS CONCLUDES THE INSTALLATION PROCESS. REPLACE THE FACTORY PANELS AND SEATS. QUESTIONS? PLEASE CONTACT SSV WORKS AT 818-991-1778 OR EMAIL SUPPORT@SSVWORKS.COM © 2023 SSV Works, Oxnard, CA 93030 RG4-Q3V1 8-30-23...
