E. Place the speaker pod in location and resecure the factory screws through the pod brackets on the front and underneath the dash.
P. From the inside-top of the dash, secure the top mounting M6 screw and large washer to the pod through the smaller hole next to the routed speaker
wire (figure F1). Then connect the B-H2935 Front Speaker "Y" harness to the speaker cable coming out of the speaker pods (figure F2).
RGB LED FRONT KICK PODS WIRING DIAGRAM
B
E
F1
A
1
F1
B
1 RGB Front Speaker Harness, 4 ft.
Detail
Connect Front Output from B-H2605 to B-H1909
A
Connect Speaker Pods connectors to B-H2935
B
15
E
Description
B-H2935
Description
F2
Part #
15
