SSV Works RG4-Q3V1 Manual page 14

FRONT RGB LED KICK PODS PARTS LIST
PARTS LIST IMAGES
1. RG4-F65V Enclosures
(1 pair)
RGB LED FRONT KICK PODS ASSEMBLY
TOOLS NEEDED FOR INSTALLATION
A. Using the supplied M6 screws and small washers, install the
brackets to kick pods.
C. Remove factory T25 torx screws located underneath the dash.
14
2. Enclosure Brackets x 4 3. M6 x 16mm Screws
x 10
- T-30 Torx Driver - Panel Removal Tool
A
B. Remove factory T40 torx screws located from the front of the
dash next to the cup holders.
14
C
D. Located on the inside top of the pocket you will have two
holes, route speaker wire though the larger hole. The smaller
hole will be used to mount the pod in Step P.
4. M6 Washers x 8 (small)
- Phillips Screwdriver
4. M6 Washers x 2 (large)
B
D
