G. With the brackets seated into one another,
use the front mounting tabs as a template
to mark with a scribe or punch the needed
placement to drill pilot holes.
SUBWOOFER WIRING DIAGRAM
1
Description
1
800.5 Amplifier 32-Pin Universal Harness
2
2-Pin Audio, Sub Extension Harness
G
H. Once marked, remove the enclosure. Using a
13/64" drill bit, drill pilot holes at your marked
points. Be sure to penetrate through the
chassis lying beneath the floorboard.
J. Connect sub to harness B-H2702.
A
2
Part #
B-H2605
B-H2702
H
I. . Re-install the sub-enclosure. Secure the front
mounting tabs with the kit provide T30 torx
self-tapping screws.
J
B
Detail
Connect Subwoofer Output from B-H2605 to B-H2702
A
Connect B-H2702 directly to the Subwoofer
B
Description
I
