Installation and Operational
Operation Instructions
Keypad style and functions may vary according to tub model, therapeutic features and selected options. Whirlpool packages vary and
may be personalized to include optional micro jets (See pg. 26).

Airbath Elite with Whirlpool

spa
mode
Digital System 6
AIRBATH
1st Press: Blower starts. LED indicator light on.
2nd Press: Blower stops. LED indicator light off.
NOTE: Blower automatically stops after 20 minutes.
AIR MASSAGE MODE
1st Press (Wave): Speed will vary gradually from maximum to minimum. LED turns on.
2nd Press (Pulse): Speed will go directly to minimum and then straight back to maximum. LED light flashes.
3rd Press (Max): Returns speed to maximum. LED indicator light turns off.
WHIRLPOOL
1st Press: Pump starts.
2nd Press: Pump stops.
NOTE: If whirlpool is equipped with optional micro jets, be sure the cluster control diverter is in the "OFF" position before
activating the whirlpool. See pg. 26 for operation details for these high-powered jets.
CHROMATHERAPY
1st Press: System powers on white LED light. Use arrow buttons to change colors.
2nd Press: Slow rainbow mode cycles through all colors. Use arrow buttons to adjust speed.
3rd Press: Slow aqua-blue-green cycle. Use arrow buttons to adjust speed.
Press and hold at any time to turn off.
THERAPIES CONTROL
Use arrow buttons to gradually adjust airbath intensity.
Use arrow buttons to change light color and adjust color cycle speed.
NOTE: Up and down arrow buttons operate the last therapy feature activated.
WHIRLPOOL JETS OPERATION (air volume control)
ADJUSTMENT: Rotate the control counter-clockwise to increase the amount of air and pressure in the system. If
your tub is equipped with a cleaning system, the detergent dispenser is also the air volume control.
⁴ MTI will not be responsible for water damage in areas outside of the tub caused by improper operation.
Visit https://mtibaths.com/media-news/videos/support-videos/
Manual •
Designer
(continued)
spa
mode
for detailed operation instructions.
Collection •
Whirlpool and Airbaths
SPA MODE FOR AIRBATH AND CHROMATHERAPY
1st Press: Spa Mode starts. Use arrow buttons to
select preferred pattern. Automatically shuts off after
20 minutes.
2nd Press: Spa Mode stops.
mtibaths.com / 23
