Installation and Operational
Operation Instructions
Keypad style and functions may vary according to tub model, therapeutic features and selected options. Whirlpool packages vary and
may be personalized to include optional micro jets (See pg. 26).

Airbath with Whirlpool

System 3
WHIRLPOOL
1st Press: Pump starts. LED indicator light on.
2nd Press: Pump stops. LED indicator light off.
NOTE: If whirlpool is equipped with optional micro jets, be sure the cluster control diverter is in the "OFF" position before
activating the whirlpool. See pg. 26 for operation details for these high-powered jets.
AIRBATH
1st Press: Blower starts. LED indicator light on.
2nd Press: Blower stops. LED indicator light off.
NOTE: Blower automatically stops after 20 minutes.
THERAPY CONTROL
Use arrow buttons to gradually adjust airbath intensity.
AIR MASSAGE MODE
1st Press (Wave): Speed will vary gradually from maximum to minimum. LED turns on.
2nd Press (Pulse): Speed will go directly to minimum and then straight back to maximum. LED light flashes.
3rd Press (Max): Returns speed to maximum. LED indicator light turns off.
WHIRLPOOL JETS OPERATION (air volume control)
ADJUSTMENT: Rotate the control counter-clockwise to increase the amount of air and pressure in the system. If
your tub is equipped with a cleaning system, the detergent dispenser is also the air volume control.
Airbath Drying Cycle
Floor sensors near drain activate drying cycle approximately 7 minutes after the bath is drained. Drying cycle will run for 1-2 minutes.
Airbath LED indicator light will blink during countdown. See details on pg. 24.
⁴ MTI will not be responsible for water damage in areas outside of the tub caused by improper operation.
Visit https://mtibaths.com/media-news/videos/support-videos/
Manual •
Designer
(continued)
for detailed operation instructions.
Collection •
Whirlpool and Airbaths
mtibaths.com / 21
