- Page 1 D E S I G N E R C O L L E C T I O N ® F r e e s t a n d i n g a n d S c u l p t e d F i n i s h Tu b s I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L...
- Page 2 WARNING: WHEN USING ELECTRICAL PRODUCTS, BASIC PRECAUTIONS SHOULD BE FOLLOWED, INCLUDING THE FOLLOWING This manual contains information and instructions for proper operation and maintenance of your MTI bathtub. Failure to follow these instructions could result in personal injury, electrical shock or fire.
- Page 3 ▲ Do not operate this unit without guard over the suction fitting. ▲ The water in a hydrotherapy bath should never exceed 40˚ C (104˚ F). Water temperatures between 38˚ C (100˚ F) and 40˚ C (104˚ F) are considered safe for a healthy adult. Use time should be limited to approximately 10 minutes, followed by a shower to cool down.
-
Page 4: Table Of Contents
16" x 14" for installation and future servicing of the equipment. MTI Baths, Inc. will not authorize any service unless clear access is available. Access from a crawlspace or incomplete access to all equipment may result in... -
Page 5: Installation And Operation Guidelines
Read all instructions before installing tub. Installer / product owner is responsible for complying with all state and local codes. Warranty coverage will be void if unit is not tested and installed per the enclosed instructions. MTI strongly recommends using licensed professionals to install this product. Warning: Certain cleaning products will perma- nently damage the acrylic surface. -
Page 6: Rough-In Measurements
* Due to the concave shape of the model 82, the edge of the tub at the overflow is inset from the corners. Use these measurements when estimating distance from the wall to center of tub or drain. Note: All specifications are subject to change without notice. MTI recommends measuring your specific tub on site. - Page 7 Every MTI air blower is supplied with a 29" grounded plug to be plugged into a grounded receptacle. Do not remove this plug. If a wall mount switch is desired to control use of the unit, the switch should control the receptacle.
-
Page 8: Freestanding Bath General Guidelines
Drain and Overflow – Due to limited space between the inner and outer tub shells, use care when selecting your drain kit. MTI offers toe tap, lift & turn and cable driven style waste and overflow kits for our freestanding tubs. We recommend using the cable driven drain kit. This style incorporates a flexible section between the overflow and the “T,”... -
Page 9: Freestanding Bath Installation Instructions
FREESTANDING BATH INSTALLATION INSTRUCTIONS See next page for installation instructions for Sculpted Finish tubs and additional air bath instructions. See page 9 for Clawfoot tub instructions. Determine final location of tub. The tub will sit on top of the finished floor, however, the drain will sit approximately 1/2"... -
Page 10: Air Bath Installation Instructions
AIR BATH INSTALLATION INSTRUCTIONS Select the location for the air blower within 8' of the tub. MTI does not recommend that the the blower be mounted more than 8' from the tub. The blower must be in a climate-controlled environment. - Page 11 Every home is different and there may be other desirable locations. Keep in mind that the blower must be accessible for any future servicing and kept in a climate controlled environment. MTI’s blower box, built of hardwood and available in several finishes, is another option for hiding the blower.
-
Page 12: Optional Equipment Installation & Operation Guidelines
In all installation situations for both tubs and seated shower bases, access to the transformer needs to be provided. In some cases, the tub may need to be lifted up to access the Radiance control box. MTI is not responsible for obtaining access for warranty service. Rectangular touchpad... - Page 13 INSTALLATION INSTRUCTIONS FOR CLAWFOOT TUBS All MTI clawfoot tubs require an exposed drain kit. MTI recommends the use of our drain kit to ensure a perfect fit. This tub is designed to have the drain (back) side of the tub face the wall. Set tub in final location, and use a 6"...
-
Page 14: Operating Instructions - Keypad And Tub Control
OPERATING INSTRUCTIONS - KEYPAD & TUB CONTROL FUNCTIONS FOR AIR BATHS Keypads and functions will vary depending on specific model and/or options purchased. Use the photos on the following pages to locate your keypad and simply follow the step by step instructions. #1 STANDARD AIR SYSTEM FUNCTIONS ON/OFF:... - Page 15 #4 AIR SYSTEM WITH LED LIGHT FUNCTIONS ON/OFF FOR AIR SYSTEM 1st Press: The blower turns on at 30% power. Use the up and down arrows to increase or decrease the speed. Please note: 20% is the minimum. If the lights for the up & down arrows go off, they can be reactivated by gently pressing the on/off button 2nd Press: The blower turns off.
- Page 16 AUTOMATIC PURGE / DRYING CYCLE FOR AIR SYSTEMS Each MTI air system is equipped with sensors on the floor of the bath near the drain. Every time water is introduced to the bath and drained, either by showering, bathing or cleaning or the air bath is activated, the sensors will activate the purge/drying cycle.
- Page 17 INDEPENDENT CHROMATHERAPY SYSTEM FUNCTIONS ON/OFF BUTTON: 1st Press: White light. LED light on (White is only available when the system is initially turned on). 2nd Press: Light off. LED light off. Press the on/off button - Light must be on for any mode to function. MODE BUTTON FUNCTIONS: 1st Press: Aqua-Blue-Green Cycle.
-
Page 18: Cleaning Instructions For The Acrylic Shell
CLEANING INSTRUCTIONS FOR THE ACRYLIC SHELL The cross-linked cast acrylic surface of all MTI air baths and soaking baths is among the glossiest, highest quality surfaces available. Its hard, non-porous surface prevents dirt from accumulating and resists stains bet- ter than other materials. With normal use, cast acrylic will retain its beauty with only a minimal amount of care. -
Page 19: Troubleshooting
Q. My MTI air bath appears to just turn on even if we are not in the tub. A. Each MTI Designer Collection air bath is equipped with a pair of sensors near the drain of the bath. They appear as two small chrome buttons. Every time water is introduced into the bath, even if the air system was not used, the air system will automatically activate approximately 7 minutes after the water has drained out of the tub in order to purge the system of any small droplets of water. - Page 20 Q. How can I get scratches out of my acrylic tub? A. Most scratches can be buffed out using an automotive polish. Any polish suitable for use on "clear coated" automobile paint is fine. Deeper scratches and chips may require the services of a professional acrylic repair technician.
-
Page 21: Residential Warranty
Warranty: MTI warrants Radiance for two-years, parts only, against manufacturing defects. If the control box or keypad fails within the two year period, MTI will send replacement parts out at no charge. In the unlikely event that the electrical heating grid fails within the two-year period, MTI Baths’ only obligation is to refund the purchase price of the Radiance system to the original product owner. - Page 22 Notice must be given to: MTI Baths, 670 N. Price Rd., Sugar Hill, GA 30518, Attn: Service Dept. MTI reserves the right to inspect the malfunction or defect on site and determine appropriate course of action.
-
Page 23: Commercial Warranty
The bath must be water tested for operation and leaks prior to final enclosure of the unit. Failure to do so will void warranty. If a problem is discovered after the final enclosure, MTI will not be responsible for the cost of removing or reinstalling the tub, or for costs associated with any adjacent materials. - Page 24 Notice must be given to: MTI Baths, 670 N. Price Rd., Sugar Hill, GA 30518, Attn: Service Dept. MTI reserves the right to inspect the malfunction or defect on site and determine appropriate course of action.
- Page 25 NOTES...
- Page 27 Manufactured by MTI Baths, Inc. mtibaths.com 670 N. Price Road Sugar Hill, GA 30518 800 783 8827 770 271 8228 Fax 800 438 8827 © Copyright 2014 by MTI Baths, Inc. Modification Rights Reserved. 0615 Part # DCTUBFS...
