MTI Matrix System Series Manual

Hide thumbs Also See for Matrix System Series:
Table of Contents

Advertisement

Quick Links

Matrix
Systems
®
063-0145-00 » Rev B » 08/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matrix System Series and is the answer not in the manual?

Questions and answers

Related Manuals for MTI Matrix System Series

Summary of Contents for MTI Matrix System Series

  • Page 1 Matrix Systems ® 063-0145-00 » Rev B » 08/02...

  • Page 2: Table Of Contents

    INTRODUCTION The Matrix System ® ....................9 Using This Manual ....................10 What To Read ......................10 About MTi ......................11 Customer Service ....................12 Custom Displays ....................12 ® MEET THE MATRIX SYSTEM What is a Matrix? ....................13 Passive Switching ....................
  • Page 3 Matrix System ® MVP Speaker Equalizer ................31 Sales Benefits ................31 How the MVP Speaker Equalizer Does its Job ........ 32 Calibrating Speakers with the MVP Speaker Equalizer ....32 MVP Speaker Equalizer, Side View ..........33 Audio MVP Control Module ............34 MVP Infra-Red Remote Control ................
  • Page 4 Contents 7.a Bypass Positions ..............66 7.b Input/Output Switching ............66 7.c Activating Multiple Components in a Chain ......66 C. MVP Control Panel Installation ................67 1. Plan the MVP Control Panel Layout ............67 2. Mount the MVP Control Panel Frame ............ 68 3.
  • Page 5 Matrix System ® ® MATRIX SYSTEM OPERATION Programming and Using ..................107 Memory Backup ..................107 Key Entry Timing ..................107 Operating The MVP Infra-Red Remote Control ........108 Selecting Components ................109 The Lock-Out Feature ................110 To Change or Reveal The Lock-Out Code ........110 Activating/Deactivating Lock-Out Feature ........
  • Page 6 Index Index TABLE OF ILLUSTRATIONS Figure 1 – Typical Matrix Applications ............9 Figure 2 – What To Read ................10 Figure 3 – The Matrix Concept ..............13 Figure 4 – A Typical MVP Control Panel ............. 17 ® Figure 5 –...
  • Page 7 Matrix System ® Figure 36 – Rear View of the MVP with Data and Control Connections..69 Figure 37 – MVP Watt Meter Installation ........... 70 Figure 38a –Speaker Impedance Levels ............Figure 38b –Speaker Impedance Levels ............. Figure 39 – Installation of MVP Sound Pressure Meter and MVP Speaker Equalizer ................
  • Page 8 Introduction...

  • Page 9: The Matrix System

    The retailer who can demonstrate a great variety of systems with ease, style, and to the performance limits of each individual component, will be the retailer who will sell the most product. MTi‘s Matrix System ®...

  • Page 10: Using This Manual

    System from the palm of your hand; a Watt Meter; a Sound Pressure Meter; and a Speaker Equalizer (see pages 27-36 for a detailed description of these features). Using This Manual This manual has been organized for all MTi customers, with special emphasis for those new to the Matrix ® System .

  • Page 11: About Mti

    But if the whole project turns out to be more of a challenge than you’re ready for, remember that our Field Service Technicians can come to your location to help you with your installation and/or service. Call MTi Customer Service for more information (see below).

  • Page 12: Customer Service

    Don’t hesitate to call, that’s what we’re here for. Our e- mail address is cservice@mti-interactive.com. And our FAX number, if you want to send us a picture of your challenge, is (503) 648-7500.

  • Page 13: Meet The Matrix System

    There is one central idea underlying the Matrix System ® from MTi — that you should be able to demonstrate any and all of the components in your System as they were meant to be demonstrated, in any combination, with minimum effort. We have engineered the logic into our switching systems to give you maximum flexibility and selling power.

  • Page 14: Passive Switching

    Switching Modules can be added and assigned the same selection number. Passive Switching All MTi switching products are passive switching systems, which do not affect in any way the audio/video signal that is being switched. This ensures that any audio or video component being demonstrated with one of our systems exhibits its true range of capability.

  • Page 15: Bypass

    Module in a Chain that has a bypass would switch only seven. Switching for All Applications Because audio/video components differ in their input/output requirements, MTi manufactures a number of different Switching Modules, each with a different configuration of input/output capabilities. (See Figure 20, page 39, for a complete listing.) Each Module contains one or two sets of eight component connection...
  • Page 16 Introduction...

  • Page 17: Product Descriptions

    Matrix System ® PRODUCT DESCRIPTIONS The MVP Control Panel A typical MVP Control Panel consists of a single MVP Control Module and several Dual Chain Modules, one for each two Chains in your System. In addition, you may have chosen to include Feature Modules in your System, such as Watt Meters, and a Sound Pressure Meter with Speaker Equalizers (see pages 27-33).

  • Page 18: Matrix System ® Mvp Features

    Descriptions For example, the System operator would select a source by entering its number, e.g. tape player 12. The number 12 will be displayed in the LED window of the main MVP Control Panel. The operator then selects the source Chain by pressing its button, and the component number 12 transfers to the LED window of the Source Chain Module.
  • Page 19 Matrix System ® Component Auto-Rotate – Activating this feature allows the MVP Control Module to automatically rotate (at programmable intervals) any quantity of components within a Chain, in a pre-chosen low to high sequence. This feature can be used to demonstrate different performance characteristics of a group of like components in product demonstrations for customers or during sales training.

  • Page 20: Matrix System Mvp Control Panel Modules

    Descriptions Matrix System ® MVP Control Panel Modules Model Description MVP-CM MVP Control Module – numeric selection and function buttons on the CM allow the user to control all system functions from one location. MVP-DCM Dual Chain Module – provides a selection button and a connection point for two component chains.

  • Page 21: Mvp Control Module

    Matrix System ® Infra-Red Remote Sensor Display (concealed) Window Compare COMPARE Numeric Keys Component Auto-Rotate Reset ROTATE (concealed) Inactivity (concealed) System Lock-Out LOCK SYSTEM INC. MATRIX SYSTEMS System SWITCHING SYSTEMS Figure 6 – MVP 1-30 PATENT 4,281,314 Control Module, Front Panel 6"...

  • Page 22: Mvp Control Module, Rear View

    MVP Control Module and Dual Chain Modules. C. MVP Control Module Power Supply Connectors – Two four-pin connector for connecting a power supply to the MVP Control Module. D. Serial Connector – a four-pin connector which is a serial interface that allows MTi’s Matrix System ®...

  • Page 23: Mvp Control Panel Power Supply

    Matrix System ® MVP Control Panel Power Supply ® At least one 12V power supply is included with each Matrix System . The 1.5 amp power supply will power the MVP Control Module and one additional Module. For larger Systems, 3 amp and 7 amp power supplies are also available.

  • Page 24: Mvp Chain Modules

    SOURCE adjacent to the slots on the left- hand side of the Module. The labels are available pre-printed from MTi or can be custom- 5.25" made. One set is provided with each MVP Control Module purchased. C. Chain Selection Buttons –...

  • Page 25: Mvp Dual Chain Module, Side View

    Matrix System ® MVP Dual Chain Module, Side View A. Switching Module Connectors– the Control Cable from the first 3 " Switching Module of the associated Chain attaches to these male-ended connectors; CH0 is for attaching to the Chain associated with the top button of the Dual Chain Module, CH1 is for the Chain associated with thelower button.

  • Page 26: Mvp Blank Chain Module

    Descriptions Chain. Selected components remain continually connected to the signal path during component rotation, A/B comparisons and normal component selection unless changed or deactivated. • Speaker Setting – Autosound Speakers tend to pop unless removed from the signal path during a component change. Therefore, setting the DIP Switch for Speaker causes that Chain to adhere to the dropout delay parameter set on the MVP Control Module DIP Switch.

  • Page 27: Mvp Feature Modules

    Matrix System ® MVP Feature Modules To complement the basic Modules, MTi has developed several Feature Modules that will increase the selling power of your MTi Matrix System ® . Each Feature Module has the same WATTS -400- dimensions as a Dual Chain Module and can easily be installed -200- as a part of a new or an existing MVP Control Panel.

  • Page 28: Mvp Watt Meter, Side View

    (4 ohm or 8 ohm) for Watt Meter. These are set during installation, but can be changed at any time. The settings of these jumpers will affect the response of the Watt Meter measurements. See page 70 for Installation instructions. If 1 ohm or 2 ohm impedance levels are needed, call MTi.

  • Page 29: Mvp Sound Pressure Meter

    The MVP-SP can be operated as a stand-alone device in any audio display. But it is specifically designed for use with MTi’s Speaker Equalizer (MVP-SE – see below) which uses the MVP- SP output to determine the attenuation level for Speakers.

  • Page 30: Mvp Sound Pressure Meter, Side View

    Descriptions MVP Sound Pressure Meter, Side View A. Microphone Input Jack – 3 " the microphone which supplies the MVP-SP with the demonstration area sound level plugs in here. See Installation Section for information on proper positioning of the microphone. B.

  • Page 31: Mvp Speaker Equalizer

    This often causes listeners to have difficulty in evaluating Speaker characteristics without being biased by changing volume levels. So MTi offers the MVP Speaker Equalizer, to equalize volume levels from all selected Speakers in a display.

  • Page 32: How The Mvp Speaker Equalizer Does Its Job

    Descriptions How the Speaker Equalizer Does its Job The Speaker Equalizer consists of two parts: 1. The Speaker Equalizer Module (MVP-SE) which is installed in the MVP frame; and 2. The Audio MVP Control Module (MVP-ACM) which is installed in the low-level audio path prior to amplification.

  • Page 33: Mvp Speaker Equalizer, Side View

    Matrix System ® MVP Speaker Equalizer, Side View 3 " A. Speaker Chain Output – Passes component selection information from an MVP Chain Module to the Speaker Chain of Switching Modules through a cable connected to the first Switching Module of the associated Speaker Chain.

  • Page 34: Audio Mvp Control Module

    A. 16v AC Power In – The ACM has its own 16v AC wall-mount transformer and plug, supplied by MTi. Do not attempt to hook up any other form of power! B. SE Module Input – A cable runs from the output of the MVP-SE into this terminal.

  • Page 35: Mvp Infra-Red Remote Control

    Matrix System ® Infra-Red Remote Control Located on the MVP Control Module, inside the upper black bar, is an Infra-Red Remote Sensor. It receives signals transmitted from the hand-held Remote Control. The Remote Control affords substantial flexibility during product demonstrations. The user may move freely about the showroom while maintaining complete control of the demons tration.
  • Page 36 Descriptions In order to prevent the accidental activation of multiple on-premise MVP Control Panels, the Infra-Red Remote Control has a limited range of about twenty-five feet and must be pointed at the MVP Control Panel to operate. The keys on the Remote may be considered to be in parallel with the same keys on the MVP Control Module.

  • Page 37: Mvp Control Panel Mounting Frames

    Matrix System ® MVP Control Panel Mounting Frames Two styles of mounting frames are available for securing the MVP Control Panel to a display system. Both styles are available in sizes ranging from six to 14 inches wide accommodating different quantities and configurations of MVP Control Panel Modules.

  • Page 38: Shelf Mount

    Descriptions Shelf Mount An on-the-shelf version typical of, but not limited to, home audio and video applications. The MVP Control Panel is first mounted in the Shelf Mount housing, then the housing is either mounted on the shelf surface or suspended from the underside. (Illustration shows unit ready to mount under a shelf.) Constructed of brushed aluminum and finished in black to match the MVP Control Panel Modules, the unit is lightweight and durable.

  • Page 39: Matrix System ® Switching Modules

    Each Switching Module is supplied with an eight-foot Control Cable which connects the Switching Modules to one another and to the MVP Control Panel. Longer Control Cables may be ordered from MTi. In the following chart, Modules with 12V Turn-On Strips are listed in bold type.

  • Page 40: 1210/1214 Switching Modules

    Descriptions 1210/1214 Switching Modules The models 1210/14 are low-level (preamp) or composite video Switching Modules, capable of switching the two channel inputs or outputs of up to eight audio or composite video components. The 1210/14 Modules have eight pairs (left and right channels) of RCA connectors for plugging in the inputs and outputs of components.
  • Page 41 Chain and from Chain to Chain to form the signal bus. They are labeled “In” at the top and “Out” at the bottom for convenience only – as with all MTi Switching Modules, the connectors are parallel; either set may be used for incoming or outgoing signals.

  • Page 42: 1240/1242 Switching Modules

    All low level signals are linked to these Modules with RCA connectors. Like MTi's other Switching Modules, the 1240 and 1242 have non-directional signal paths. With the input of a component connected to one section of the module and the output connected to another, both sides switch simultaneously when the component is selected.
  • Page 43 Matrix System ® A. LED – Indicates that this Module is activated (active or bypassed). B. DIP Switch – Using binary code, designates Component Selection Numbers for each Switching Module (e.g. Module 2 in PEQ/XO Chain; Positions 4–7). See Appendix A for DIP switch setting instructions.

  • Page 44: 1310/1312 Switching Modules

    2-Channel signals from the same components (at the same Position). If you have a display that was built by MTi, the high-level connectors on your 1310/1312 Switching Modules have MTA connectors instead of screw terminals. All functions are identical.
  • Page 45 Matrix System ® A. LED – Indicates that this Module is activated (active or bypassed). B. DIP Switch – Using binary code, designates Component Selection Numbers for each Switching Module (e.g. Module 2 in Front Deck Chain; Positions 8–15). See Appendix A for Dip Switch setting instructions.

  • Page 46: 1320/1322 Switching Modules

    Modules with RCA connectors. Like MTi’s other Switching Modules, the 1320 and 1322 have a non-directional signal path and can switch a signal in either direction. The input stage of a component can be connected to one side of the Module, and the output stage connected to the corresponding Position on the other.
  • Page 47 Matrix System ® A. LED – Indicates that this Module is activated (active or bypassed). B. DIP Switch – Using binary code, designates Component Selection Numbers for each Switching Module (e.g. Module 2 in PEQ/XO Chain; Positions 8-15). See Appendix A for DIP Switch setting instructions.

  • Page 48: 1410/1412 Switching Modules

    Out-of-phase cone vibrations can occur in Speakers that have not been selected, especially if they are in the same enclosure. To prevent this, MTi provides a set of jumper positions on the 1410/12. When the jumpers are installed, the coils of non-selected Speakers are shorted and the cone movement is inhibited. When a 1410/12 is used to switch other components, the jumpers should be left off.
  • Page 49 Matrix System ® A. LED – Indicates that this Module is activated (active or bypassed). B. DIP Switch – Using binary code, designates Component Selection Numbers for each Switching Module (e.g. Module 2 in Speaker Chain, Positions 8–15). See Appendix A for DIP Switch setting instructions.

  • Page 50: 1440 / 1442 Switching Module

    Descriptions 1440/1442 Switching Modules The 1440 high-level, high-power switching module is the answer to high-power requirements. Similar to all other Matrix System Modules, the 1440 supports up to eight 2-Channel signals and additional Modules can be added in series to switch virtually any quantity of high-level signals. The 1440 Module is larger and heavier than other Matrix Switching Modules.
  • Page 51 Matrix System ® A. DIP Switch – Using binary code, designates Component Selection Numbers for each Switching Module (e.g. Module 2 in Speaker Chain, Positions 8–15). See Appendix A for DIP Switch setting instructions. B. LED – Indicates that this Module is activated (active or bypassed). C.

  • Page 52: 1820 S-Vhs Switching Module

    This Module enables the retailer to include Hi-Fi, Stereo S-VHS camcorders and VCRs in a Home Theater or Video display. Standard VHS components can be switched with MTi’s Model 1210 or 1320 Low-level Switching Modules. The left side of the 1820 is like other low-level Switching Modules. The right side consists of component connectors and bus connectors for S-VHS Video Components.
  • Page 53 Matrix System ® A. LED – Indicates that this Module is activated. B. DIP Switch – Using binary code, designates Component Selection Numbers for each Switching Module (e.g. Module 2 in VCR Chain; Positions 8–15). See DIP Switch setting instructions, Appendix A. C.

  • Page 54: Switching Module Applications

    Descriptions Switching Module Applications Input and/or Output Switching Each Matrix System Switching Module can handle either input or output signals, and in the case of Switching Modules with two sides (1310/12, 1320/22), the same Module can sometimes handle both (see below).

  • Page 55: Switching Multi-Channel Components

    Matrix System ® Switching Multi-Channel Components Many components in both home and car audio have more than one set of inputs and/or outputs. When a multi-channel component position is selected at the MVP Control Panel, a Switching System must have the potential to switch any of that component’s inputs or outputs simultaneously.

  • Page 56: Figure 30 - Using Two Modules To Switch One Component

    Descriptions If more channel capacity is needed, two or more Switching Modules may be used in parallel. All Modules switching the same components require the same DIP Switch “address.” High Level Rear Output Tape Deck #1 High Level Front Output Speak er (L 1312...

  • Page 57: Auxiliary Equipment

    DC power supplies for components and switching. MTi carries a full line of power supplies to meet any DC power requirements. From smaller 800 mA to 75 amp. Two power supplies can be paralleled when more power is required.

  • Page 58: Component Installation Accessories

    Terminal Strips are recommended for use when connecting Power Supplies to their respective destinations. Available in three-position and up. Antenna System Hardware for both home and car audio and video displays is available from MTi. We carry a variety of antennas, cables, and connectors.

  • Page 59: Matrix System Installation

    Matrix System ® ® MATRIX SYSTEM INSTALLATION The following section is organized to reflect the four major stages of the installation process: A. Preparation C. MVP Control Panel Installation B. Switching Module Installation and Wiring D. Component Wiring and Testing Within each stage, action items are numbered in the sequence you should follow to install a complete Matrix System.

  • Page 60: Checking Your Space

    • Plastic tie wraps, eye ties and screws for securing wire bundles. • Labels for cable ends. (MTi sells sheets of adhesive numbers for this purpose – talk to our Sales or Customer Service department.) • A telephone (preferably cordless) – we encourage you to call our Customer Service department with any questions that arise during the installation process or at any time that we can help you with the use of your MTi Switching and Display System –...

  • Page 61: Some Basic Principles

    Use at least 18 gauge wire for high-level wiring and 10 gauge wire for Amplifier power and ground. At MTi, we use a double wire from each terminal strip to the power source to ensure safe and efficient power transmission. A little extra attention devoted to wiring during installation will ensure that you get optimum performance from your System.

  • Page 62: Wiring Color Code

    Installation MTi Suggested Wire Color Code Black Ground Switched 12V Yellow Memory/Constant Green L+ Front White L- Front R+ Front Black R- Front Green L+ Rear White L- Rear R+ Rear Black R- Rear Green L+ Sub White L- Subr...

  • Page 63: Figure 34 - Example Of Installed Switching Module With Labeling And Wiring Tied Down

    Matrix System ® MATRIX MODEL 131 Customer-labeled Customer- Switching labeled Designation Component Position Numbers 10 11 10 11 12 13 Eye Ties 14 15 14 15 Tie Wrap REAR Customer-labeled Module Designation Figure 34 – Example of Installed Switching Module with Labeling and Wiring Tied Down...

  • Page 64: Switching Module Installation

    To help arrest out-of-phase cone vibration of unselected Speakers during audio demonstrations, some of MTi’s high-level Switching Modules contain a feature that causes a short in Speakers that are not selected. Jumpers (see page 71) should be placed on the Speaker Coil Shorting Pins for Speaker switching and left off when switching other components.

  • Page 65: Mount The Switching Modules

    12-connector “Mate ‘n’ Loc” terminals. Functions are identical, however, and newer Matrix System Switching Modules may be connected into an older System with special adapter cables available from MTi.) Attach the Control Cables to the first Switching Modules in each Chain at this time; they will be connected to the MVP Control Panel later.

  • Page 66: Interconnect The Signal Bus

    System require that more than one component be activated with a single Position, such as having two sets of Speakers on the same Chain play together, an MTi Customer Service Representative can help you with a special wiring method that will achieve this.

  • Page 67: Mvp Control Panel Installation

    Modules should be run in a certain order. These are the general principles that we use at MTi, and that we suggest you use to plan the layout of your MVP Control Panel: 1.1 Locate Source Modules adjacent to the MVP Control Module. Position Processor Modules below or adjacent to Sources.

  • Page 68: Mount The Mvp Control Panel Frame

    MVP Control Panel sections are screwed into their frames. MTi manufactures two different frame styles for two different applications. See pages 37-38 for illustrations of the two types of mounting frames. Both frame styles are available in a variety of sizes, from six to 14 inches wide.

  • Page 69: Dual Chain Module Data Cables

    Matrix System ® 4. Interconnect the MVP Control Module and Dual Chain Module Data Cables Each Dual Chain Module and Watt Meter comes with a multi-conductor, ribbon-type Data Cable attached near the bottom, (above the four-conductor power connectors) with an adjacent parallel male connector.

  • Page 70: Mvp Feature Module Installation

    Speakers, and the right for 4-ohm Speakers. If the Speakers in your Watt Meter Chain have a variety of impedances, choose the level for the majority of Speakers in the Chain. Should you require an impedance level of 2 ohms or less, call an MTi Customer Service Representative for assistance.

  • Page 71: Installing The Mvp Sound Pressure Meter

    Speaker Equalizers. A single MVP Sound Pressure Meter may be used with any number of Speaker Equalizers. The MVP-SP is equipped with a microphone from MTi. We strongly recommend that you use the supplied microphone, since the unit has been calibrated to operate with the response of that particular microphone.

  • Page 72: Figure 39 - Installation Of Mvp Sound Pressure Meter And Mvp

    Installation Speaker Equalizer #2 Speaker Equalizer #1 Sound Pressure Meter #2 Dual Chain Module 2 Speaker Chains #1 Dual Chain Module Source Chain, Amp Ch i Control Module Multi-Conductor Control Cables out to Switching Module Chains. Multi-Conductor Data Power Supply Cables from Dual Chain 4 Conductor Power Cable Multi-Conducter Data Cable...

  • Page 73: Connect The Mvp Control Panel Power Supply

    Matrix System ® 6. Connect the MVP Control Panel Power Supply At least one 12V DC power supply is included with each MVP System. It supplies power to the MVP Control Panel, and, through the Multi-Conductor Control Cables, to the Switching Modules. We do not recommend that you use the same Power Supply for your components and your MVP Control Panel, since transient voltages may disrupt MVP Control Panel operation.

  • Page 74: Connect The Mvp Control Panel To The Switching Modules

    (See pages 70-72 for Feature Module connections.) If the Control Cables supplied with your Switching Module are not long enough, call MTi. We manufacture these cables in many different lengths to reach from your MVP Control Panel to your Switching Module Chains.

  • Page 75: Mount The Mvp Control Panel Modules

    Component Turn-On feature, these connections should also be made at this time. 1. Install Component Connections MTi recommends that you use component connection terminals mounted near your component locations, rather than connecting components directly to Switching Modules, since it greatly simplifies component installation and replacement later on.

  • Page 76: Switched Autosound Component Power Installation

    2.a Installing the Component Power Supply Figure 40 illustrates a method for hooking up 12V DC power. This is the way MTi wires displays at the factory, and we feel it offers the most efficient and safest transfer of power. In addition, this method makes disconnection and reconnection of components quick and easy –...

  • Page 77: Paralleling Two Power Supplies

    Matrix System ® Deck Amplifier 12v Memory 18 ga. wire Ground 10 ga. wire Switched 12v+ +12v DC Switched Terminal Blocks/PDQs/ Push Terminals Component Component Turn-On Strip Turn-On Strip Switching Switching Module Module Negative Positive Dual 10 ga. wires Terminal Blocks Power Supply Figure 41 –...

  • Page 78: Connecting Component Power Turn-On Strip

    Installation 2.c Connecting Component Power Turn-On Strip MTi’s Model 1214, 1312, 1322, 1412 and 1442 Switching Modules have an on-board terminal strip with corresponding relays which can be used to switch 12V power to components (for use in Autosound displays). In certain applications they can also be used to trigger a dedicated component, such as an Amplifier used for a Subwoofer Chain.

  • Page 79: Selection Indicator Leds

    Never connect +12 volts from any source directly to the “LED+” (or “12V DC”) terminal. If you are using MTi-supplied LEDs and bezels, you will need to drill holes in your panels that are 9/32" in diameter. Then install the plastic LED sleeve from the front, secure it, and push the LED through the hole from the back until it snaps in place.

  • Page 80: Bypass Positions

    If everything checks out, refer to the Troubleshooting Section in Appendix C. If you still don’t find the problem use your ultimate tool: your trusty MTi Customer Service Representative who is waiting to help you at 1-800-426-6844.

  • Page 81: Testing An Autosound Switching System

    Matrix System ® Testing an Autosound Switching System 1. Hook up one Head Unit (tape deck, CD player, etc.) making power trigger connections and signal connections to the correct Component Connection Terminal. (See Component Installation, pages 77-78, for recommended procedures and options.) If any of the Head Units have High Level output, use one of them for this first step and skip ahead to step 3.

  • Page 82: Testing A Home Audio Switching System

    Installation Testing a Home Audio Switching System 1. Hook up one Receiver, making signal connections to the correct Component Connection Terminal. (See Component Installation, pages 77-78, for recommended procedures and options.) Plug in the component’s AC power cord. 2. Hook up one set of Speakers. (See Component Installation, pages 77-78, for recommended procedures and options.) 3.

  • Page 83: Testing A Video Switching System

    Matrix System ® Testing a Video Switching System 1. Hook up one Video Source (Camcorder or VCR), connecting video and audio signals to the correct Switching Modules. (See Component Installation, pages 77-78, for recommended procedures and options.) 2. Hook up one monitor or television. (See Component Installation, pages 77-78, for recommended procedures and options.) Activate the Video Source.
  • Page 84 Installation...

  • Page 85: Sample System Diagrams

    Matrix System ® SAMPLE SYSTEM DIAGRAMS The System Diagrams on the following pages illustrate the connections for typical Matrix System MVP applications. One of the Diagrams should be reasonably similar to the System you have, so you can use it as a model for making the connections for your display.

  • Page 86: Matrix System ® Sample Autosound System I

    Diagrams ® Matrix System • Sample Autosound System I This basic system allows for the demonstration of any head unit with a pair of front and/or rear full-range speakers. System Component Mix Switching Requirements 16 Head Units (2-Ch Hi Level with Turn-on) (H) 1412 Switching Modules Front Speaker Pairs (H) 1410 Switching Module...
  • Page 87 Matrix System ® FRT SPKR HEAD UNIT From +12V Power Supply +12V Turn On Tape Deck #1 1410 (1-8) 1412 (1-8) High Level Out (L&R) Front Speaker #1 High Level Bus (Front) From +12V Power Supply REAR SPKR 1412 (9-16) 1410 (1-8) Rear Speaker #1...
  • Page 88 Diagrams...

  • Page 89: Matrix System ® Sample Autosound System Ii

    Matrix System ® ® Matrix System • Sample Autosound System II This configuration creates a small but versatile system for the demonstration of virtually any Autosound product combination – ranging from a simple head unit and pair of full-range speakers to a full tri-amp configuration with front and rear speaker pairs and separate subwoofers with their own dedicated amplifiers.
  • Page 90 Diagrams FRT AMP HEAD UNIT From +12V From +12V Power Supply Power Supply +12V Turn On +12V Turn On Tape Deck #1 1312 1312 (0-7) (1-8) Input Low Level Out (L & R) Front Out High Level Out (L&R) Front Amplifier #1 High Level Bus (Front) Low Level...
  • Page 91 Matrix System ® FRT SPKR 1410 (1-8) Legend Low Level Bus F ront Speaker #1 + 12V Power High Level Bus Signal F low Low Signal F low High High Level Bus (F ront) 1410 (9-16) F rom + 12V Power Supply SPKR 1442...
  • Page 92 Diagrams DECKS 1-8 REAR AMPS 0-7 DECKS 9-16 SUB AMPS 0-7 DECKS 17-24 FRONT SPEAKERS 1-8 PROCESSORS 0-7 FRONT SPEAKERS 9-16 - OR - PROCESSORS 0-3 REAR SPEAKERS 1-8 FRONT AMPS 0-7 SUB SPEAKERS 1-8 DCM CH 0 DECKS F AMP R AMP S AMP PEQS...

  • Page 93: Matrix System ® Sample Autosound System Iii

    Matrix System ® ® Matrix System • Sample Autosound System III Autosound System III offers versatility for switching amplifiers and processors, as well as a large head unit capacity. Front-to-rear fading can be demonstrated with or without amplifiers. Pre-amplifier level equalizers or active crossovers can be used with virtually any combination of components, allowing the system to demonstrate both full-range and “separates”...
  • Page 94 Diagrams PROCESSOR HEAD UNIT Equalizer #1 High Level Tape Deck #1 Output (Front) From Low Level High Level +12V Power +12V Turn On Input Output (Rear) Supply Low Level Speaker (L and R) Output (Sub) +12V From Turn +12V Power 1410 1312 Supply...
  • Page 95 Matrix System ® FRONT AMP From FRT SPKR +12V Power +12V Turn On Supply 1410 (1-8) 1312 Bypass (0-7) Front Speaker #1 High Level Bus (Front) 1410 (9-16) REAR AMP From +12V Power +12V Turn On Supply 1312 (0-7) Bypass Low Level Input (Rear) High Level...
  • Page 96 Diagrams PROCESSOR HEAD UNIT Speaker (L and R) 1410 1312 (1-8) (1-8) 1242 (0-3) 1410 (9-16) 1312 (9-16) 1410 (17-24) 1312 (17-24) HEAD UNITS FRONT AMP REAR AMP SUB AMP PROCESSOR FRONT SPKR REAR SPKR SUB SPKR Figure 48 – Sample Autosound System III – Logic Connections...
  • Page 97 Matrix System ® FRONT AMP FRT SPKR 1410 (1-8) 1312 (0-7) 1410 (9-16) REAR AMP 1312 (0-7) REAR SPKR 1410 (1-8) SUB AMP 1442 (1-8) 1210 SUB SPKR (1-8) 1440 (1-8) Figure 49 – Sample Autosound System III – Logic Connections...
  • Page 98 Diagrams Legend Amps Low Level Bus High Level Bus +12V Power 1312 Rear Bypass Amps 1312 Front Bypass Amps POWER 1312 GROUND Figure 49b – Sample Autosound System III – Amplifier Wiring...

  • Page 99: Sample Home Audio System

    Matrix System ® Matrix System ® • Sample Home Audio System This System is designed to demonstrate a variety of Home Entertainment products. The Source Chain includes A/V and stereo audio components. Each component can be demonstrated through any combination of speakers in the System. Receivers in the System may include those with surround sound capability, thus allowing basic Home Theater demonstration.
  • Page 100 Diagrams RECEIVER SOURCE AUD IO VDEO RECEIVER C O M P AC T D I S K P LAY E R CD Player Receiver #1 High Level Audio Out 1210 Low Level Audio Bus 1310 (1-8) High Level Low Level Audio Bus 1310 (9-16)
  • Page 101 Matrix System ® Matrix System ® • Sample Home Theater System This System creates a full Home Theater demonstration, including laser disc players, hi-fi stereo VCRs and up to 8 surround receivers. The receivers can deliver speaker level output to front, rear, and center channel, plus low-level output to powered subwoofer speakers.
  • Page 102 Diagrams A/V SOURCES SURROUND RECEIVER AUD IO VDEO RECEIVER 10:45 DVD #1 Digital High Level High Level Audio Output Low Level Audio Output Input (Rear) Input (Center) 1320 Low Level High Level Output Sub Output (Front) (M ono) 1310 1310 1310 (1-8) (1-8)
  • Page 103 Matrix System ® Legend FRT SPKR Low Level Bus High Level Bus Signal Flow Low 1410 (1-8) Signal Flow High Signal Flow Video CENTER SPKR Front Speaker #1 1410 (1-8) Center Speaker #1 REAR SPKR High Level Bus (Center) 1410 (1-8) SUB SPKR 1210...
  • Page 104 Diagrams A/V SOURCES SURROUND RECEIVER 1320 1310 1310 1310 (1-8) (1-8) (1-8) 4000LM 4005R 4000LM 4005T 4000LM 4005R 4000LM 4005T Figure 53 – Sample Home Theater System...
  • Page 105 Matrix System ® FRT SPKR 1410 (1-8) CENTER SPKR 1410 (1-8) REAR SPKR 1410 (1-8) SUB SPKR 1210 (1-8) FRONT SPKR CENTER SPKR RECEIVERS 1 2 3 4 5 6 7 8 9 SOURCES REAR SPKR SUB SPKR Figure 54 – Sample Home Theater System...
  • Page 106 Introduction...

  • Page 107: Matrix System Operation

    Matrix System ® MATRIX SYSTEM OPERATION Programming and Using The MVP Control Panel Features This section contains the keys to programming and operation of the features of the MVP Control Panel. To reduce confusion, the programming and operating steps are presented here in graphic form by way of easy- to-follow flow diagrams.

  • Page 108: Operating The Mvp Infra-Red Remote Control

    Operation Operating The Infra-Red Remote Control The optional Infra-Red Remote Control is designed to operate almost all System features. The hand-held unit allows the user to conduct efficient product demonstrations while moving freely about the showroom. The Remote has a range of about 20 feet. (If less, check the battery.) It is fairly directional and must be pointed at and slightly down toward the MVP Control Panel to work.

  • Page 109: Selecting Components

    Matrix System ® Selecting Components Selecting components with the Matrix System MVP Control Panel is easy. Each component connected to the System has a number. Enter this number on the keypad, press the button on the correct Dual Chain Module or Watt Meter/Single Chain Module and the LED display will confirm your entry.

  • Page 110: The Lock-Out Feature

    Operation The Lock-Out Feature Press Power Lock-Out prevents unauthorized use of the Matrix Reset System MVP Control Panel. When the Lock-Out feature is activated, no functions on the MVP Control Current Lock-out code Panel may be accessed. If however, this feature is shown in activated while components are selected on the MVP Control Module Display...

  • Page 111: Activating/Deactivating Lockout Feature

    Matrix System ® Activating/Deactivating Lockout Feature To activate or deactivate Lock-Out, enter the correct code and then press the Lock-Out key. This will cause the System to enter the opposite of the state it was in. All Lock-Out functions may be addressed with the remote.

  • Page 112: Programming A/B Compare

    Operation Programming A/B Compare Follow the steps below to store systems under the A/B Compare function. To use the feature, simply press either “A” or “B” on the MVP Control Module or Remote. Any set of components playing at that time will be deactivated and the component mix stored under “A”...

  • Page 113: Programming And Selecting System 1-30

    Matrix System ® Programming and Selecting System 1–30 System 1 –30 lets you store particularly profitable and popular systems, advertised specials, manufacturers’ packages or any other groups of components that you would like to have at your fingertips. While A/B Compare is often set up during a demonstration in response to a customer’s needs, these systems are usually pre-programmed.

  • Page 114: Programming Rotate Timing

    Operation Programming Rotate Timing The Rotate feature can be programmed to play each component for any length of time from 1 second to 99 seconds. Select a length of time that will give the listener an audio sample long enough to hear the quality of the sound but not so long that the previous audio sample is forgotten.

  • Page 115: Component Auto-Rotate

    Matrix System ® Component Auto-Rotate The Auto-Rotate feature enables the user to rotate sequentially numbered components in a Chain, in sequence, at user-settable value (1-99 seconds). For example, you can set up a rotation of front Speakers 1–10, or rotate all your head units. This can be used as part of a demonstration, or when the System is idle to create interest and draw attention.

  • Page 116: Figure 63 - To Start Component Auto-Rotate

    Operation Press ROTATE Control Module Display shows “rO” I-R Remote Control Panel Press corresponding Press Chain Button numbered Chain where Component Selection Key. (1-14) Rotation is desired. If Chain is Rotating, it stops. If not, it begins Rotating. Control Module Displays a rotating graphic while feature is activated.

  • Page 117: Programming Inactivity Timing

    Matrix System ® Programming Inactivity Timing To program Inactivity Time, press 0. Then press and hold the Inactivity button on the Control Panel. To deactivate inactivity timing, press auto-clear. Programming Default System Select desired components Programming Default Time Select the number “30” on the numeric keypad Enter desired inactivity time in minutes from 1-99...

  • Page 118: Operating The Mvp Feature Modules

    Operation Operating the Feature Modules MVP Watt Meter – Use and Operation The Watt Meter, once it is installed, operates automatically. To use the Watt Meter to its full advantage, read through the Product Description on pages 27-28 of this manual so that you understand its function. MVP Sound Pressure Meter –...

  • Page 119: Speaker Equalizer

    Matrix System ® Calibrating Speakers Automatically with the Speaker Equalizer 1. Program Speaker Rotation including only the Speakers that the SE will be equalizing. 2. Turn ON the SE – When the System is powered up, the SE is in the OFF mode. 3.

  • Page 120: Calibrating Speakers Manually

    Operation Calibrating Speakers Manually Because there is such a variety in response patterns of Speakers, after the calibration process is completed, you still might want to further adjust a single Speaker pair. You can do this by simply selecting the Speaker pair, pressing CAL briefly and then pressing briefly the UP or DOWN arrow buttons until the Speakers sound right to you.
  • Page 121 Matrix System ® APPENDIX This section is included to provide you with the information necessary to troubleshoot your systems problems. This section provides examples of power supply requirements, a definition of terms and a copy of our Lifetime Limited Warranty.

  • Page 122: Dip Switch Settings

    Appendix Appendix A – DIP Switch Settings DIP Switch Settings for The MVP Control Module Located near the center of the rear circuit board on the back side of the MVP Control Module is a four- position DIP Switch (see Figure 7, page 22). The settings of this switch control two System parameters: Speaker Dropout Delay Timing –...

  • Page 123: Dip Switch Settings For The Mvp Control Module

    Matrix System ® DIP Switch Settings for MVP Dual Chain Modules and Watt Meters As with the MVP Control Module, the DIP Switch parameters should be considered and set before assembling and installing the MVP Control Panel. A complete explanation of the DIP Switch options available on a per Chain basis can be found on page 22.

  • Page 124: Modules And Watt Meters

    Appendix DIP Switch Settings for Switching Modules ® Each component in a Matrix System Display is assigned a Position number which is used to activate that component during a demonstration. Each Component Chain consists of one or more Switching Modules, depending on the number of components to be switched in that Chain.

  • Page 125: Dip Switch Settings For Switching Modules

    99 components on each Chain. (However, more components can be included with certain design modifications from MTi – call Customer Service.) Refer to the System Diagrams, pages 85-105, for a graphic representation of Modules in Chains and their designations.
  • Page 126 So, double the figure from above. 700.0 watts x 2= 1400 watts Note: MTi carries a full line of power supplies to fit any Switching System power requirements. Ask your MTi Representative, or call our Sales or Customer Service Department.

  • Page 127: Power Supply Requirement Worksheet

    Matrix System ® Step 2 Take the figure derived in step 1 and match it to the closest “Total Watts” amount in the table below. If yours is between two amounts, round up to the next highest in the Table. Total Watts Amperes Drawn 100 W...

  • Page 128: Troubleshooting

    Dual Chain Module, and disconnect the cables to the next Dual Chain Module. Continue this process, adding one more DCM at a time, until your problem recurs, and you will know which Dual Chain Module is causing the problem. Call MTi Customer Service (800-426-6844).
  • Page 129 Matrix System ® 3. If the MVP Control Panel does respond properly, then the problem is in one or more of the Chains. After reconnecting all the Dual Chain Modules to the MVP Control Module, connect one Chain at a time to its Dual Chain Module, power up the System and make several component selections on each Chain.
  • Page 130 Set DIP Switches on Switching a Chain turns on at the same on Switching Module Modules according to Appendix A time Malfunctioning Switching Module Call MTi One component is selected, Switching Module DIP Switch Check DIP Switch settings but a different component incorrect...
  • Page 131 Matrix System ® Troubleshooting Signal and Power Problems PROBLEM CAUSES SOLUTIONS Lose sound from speakers Bad RCA cable Check all low-level when path RCA cables Amplifieris selected during Amplifier demonstration Passive EQ bypass Positions not Check PEQ Module's DIP switches connected &...

  • Page 132: Limited Warranty And Repair Policy

    Appendix Troubleshooting Signal and Power Problems, Continued PROBLEM CAUSES SOLUTIONS Missing front or rear channels High-level wires making poor Check all connections (include using high-level components contact at component or Switching interconnecting wires) or use test Module connection Speaker to confirm that signal is passing to &...

  • Page 133: Glossary

    ® Appendix D - Glossary This glossary contains a combination of terminology, buzz-words and, jargon from this manual. MTi recognizes that the meaning and usage of some audio/video terms, varies in different geographical areas. Since an all-encompassing ‘Bible’ of definitions would be too lengthy in this context, we have defined these terms as they are applied in this manual.
  • Page 134 Appendix DCM – MVP Dual Chain Module Destination – A category or type of electronic component designed to receive a signal and project it to the listener/viewer. (e.g. video monitors, Speakers, etc.) Equalizer – An electronic component that divides a 2 channel signal into typically 5, 7 or 9 frequencies and allows the user to adjust the amplitude of these frequencies to the desired levels.
  • Page 135 Matrix System ® Source – An electronic component that originates an audio or video signal (e.g. Tape Deck, CD Player, VCR, Tuner, etc.) SP – MVP Sound Pressure Meter Speaker Level – A signal that does not require amplification to be heard through Speakers. Also referred to as High Level or Active.
  • Page 136 This Warranty does not cover cartons, cases, cabinets, displays, or any unit attached to or otherwise connected to an MTi product. The warranty does not cover the costs to remove or install an MTi product or any component thereof.
  • Page 137 After repair and return of the original unit from MTi, the loaner must be returned for credit. Upon receipt, MTi will reimburse the deposit amount minus any balance owing. A Visa or MasterCard credit card may also be used to...
  • Page 138 Index INDEX CAL (SE) 31, 120 0102 Component Turn-On Module 57 Calibrating Speakers with the MVP 0105 Junction Board 57 Speaker Equalizer 32, 119-120 0207 Video Buffer 57 CH0, CH1 24, 25, 27, 74 0220 Floating Ground/Common Ground Adapter 57 Chain 13-15, 64 1210/1214 Switching Modules 39, 40 Designation 125...
  • Page 139 Matrix System ® Control Module 14, 20, 21 Installation 67-75 High-Level 44, 50, 54 Power Supply Connector 23 Bus 45, 49, 51 Rear View 22 Control Panel 14, 17-19, 21 DIP Switch Settings 122-124 Installation 67-75 Infra-Red Remote Control 20, 35-36 Mounting Frames 37-38, 68 Chain Designation 125 Power Supply 23, 73...
  • Page 140 Programming Component Auto–Rotate 115 Modules) Memory Backup 19, 107 Microphone (SP) 29, 71 Input Jack 30 MTi 11, 12, 136-137 Multi-Channel Component 55 Multiple Power Supplies 77 RC (See Infra-Red Remote Control) MVP Control Module (See Control Module) Relay 14...
  • Page 141 Matrix System ® Speaker Setting (DIP Switch) 26, 125 WM (See Watt Meter) Surge Protector 61 Wiring Technique 61 Switched 12V (See Component Turn-On) Switching Capacity 14 Switching Modules 13-14, 39-53 Connectors 15, 22 DIP Switch Settings 124-125 Installation 63-66 Switching Multi-Channel Components 55-56 Switching System Power Requirements 57, 126-127 System 1-30 10, 18...

This manual is also suitable for:

Matrix system mvpMatrix system 1210Matrix system 1214Matrix system 1240Matrix system 1242Matrix system 1310 ... Show all

Table of Contents
