Whirlpool and Airbaths
Fig. 9a Fill-Flush
cleaning solution
dispenser
tub deck
flex pipe
mixed supply line
¾" NPT
to whirlpool jets
mixed water
AS-VTD-3
Fig. 9b Fill-Flush with Atmospheric Vent
atmospheric
vent
cleaning solution
dispenser
tub deck
mixed supply line
flex pipe
¾" NPT
to whirlpool jets
mixed water
AS-VTD-3
