8a. Electrical Requirements - 60Hz 8a.

Electrical Requirements - 60Hz

ALL ELECTRICAL CONNECTIONS SHOULD BE MADE BY A LICENSED ELECTRICIAN.
NOTE: The following instructions are intended for Single Phase equipment. If Three Phase equipment was ordered,
refer to the Three Phase Equipment Supplemental Guide at this time.
A Ground Fault Circuit Interrupter (GFCI) is required for this product. A GFCI is a device that shuts off an electrical circuit
when it detects that electricity is flowing along an unintended path. The path could be through a person or water. The
purpose of this device is to reduce the chance of electrical shock. The Hydraulic Power Unit requires one single phase
220v 30amp GFCI protected service.
RF
Antenna
Wifi
Antenna
B
W
W
B G/Y
Single
Line 1
B
Line 2
Phase
R
Neutral
Input
W
Ground
G/Y
21
EP3 CONTROLLER
ANT1
LEARN
AUX
(NEUTRAL) LINE 2 IN
SWITCHED OUT
SOL +
SOL -
KEYPAD
WIFI
DISPLAY
Contactor and
Terminal Blocks
T3 T3
2T1
1L1 NO
4R2 3R1 NC
6R4 5R3 NC
8T3 7L3 NO
A2 A1
T2
T1
GROUND
B W
R G/Y
LEARN SW
(and countries with a similar power supply) (and countries with a similar power supply)
LINE 1 IN
R
B B
OIL SIG -
OIL SIG +
W
B
T2
T1
W
B G/Y
HYDRAULIC POWER UNIT
Float
Level
R
Switch
Proportional
Valve
Line 1
B
Line 2
R
Ground
G/Y
Hydraulic Power
Unit (HPU)
R
