Endless Pools HYDROSTRIDE Owner's Manual page 17

3. Apply Teflon tape to the threads of the Liquid Tight Fittings (A) and then install the fittings onto the Sub Hoses (B).
There is red tape wrapped around one of the Sub Hoses (B) and one of the Run Hoses (C) representing low-pressure.
Attach the Sub Hose with the red tape to the Run Hose with the red tape. Attach the other Sub Hose (high-pressure)
to the remaining Run Hose. Feed the hoses into the conduit (Fig. 15).
Fig. 15
4. Thread the Liquid Tight Fittings (A) into the Bushing Reducers and tighten the compression nuts. Secure Sub Hoses
with Hose Clamps (B) as shown using the 3/4" (19mm) Phillips Truss Head Screws (C) (Fig. 16).
Fig. 16
C
B
A
A
C
B
16
