Endless Pools HYDROSTRIDE Owner's Manual page 18

5. Attach the Lower Cover (A) to the Hydrostride using the 1" (25mm) Phillips Truss Head Screws (B) (Fig. 17).
Fig. 17
6. Attach the Grab Bar (A) to the pool wall using the 1-1/4" (32mm) Hex Head Bolts (B). The bolts will thread into the
Couplers or Rivet Nuts that were installed into the pool wall during the mounting kit installation. If being installed in a
pool with a vinyl liner, apply silicone around the front and back of the mounting holes, in the flanges of the Grab Bar,
prior to installing (Fig. 18).
A
B
Fig. 18
7. Prior to filling the pool, it is necessary to perform a continuity test to ensure the Hydrostride and Grab Bar are
Refer to Section 9 for detailed instructions.
properly bonded.
17
C
A
B
