Endless Pools HYDROSTRIDE Owner's Manual page 12

5. Prior to attaching the two End Covers, the covers MUST be modified to account for the radius at the bottom of the
pool wall, where the wall meets the floor, (if a radius is present). Attach the End Covers (A) and (B) to the Hydrostride
using the 1" Phillips Truss Head Screws (C) and 1" Phillips Flat Head Screws (D). DO NOT install a screw in location (E)
at this time. This screw will be installed in the following step (Fig. 7).
Fig. 7
6. Included in the installation kit is a #8 Solid Insulated Copper Bonding Wire which MUST be attached at this time.
In addition, if the Hydrostride is being installed in a pool using a salt-chlorine generator, the Sacrificial Zinc Anode
MUST be installed to combat the corrosive nature of the salt.
Attach the lanyard of the Zinc Anode (A) (salt pools ONLY) to the 1" (25mm) Machine Screw (B) and then insert the
screw through the hole in the End Cover. Attach Bonding Wire (C), pre-attached to the Hydrostride, and the loose
Bonding Wire (D) from the installation kit, to the screw. Secure wires with Nut (E) (Fig. 8).
B
A
11
E
A
D
E
C
C
D
THE ANODE SHOULD ONLY BE USED IN SALT POOLS.
B
Fig. 8
