Endless Pools HYDROSTRIDE Owner's Manual page 16

FOR GUNITE POOL INSTALLATIONS, FOLLOW STEP 2A. IF BEING INSTALLED IN A POOL WITH A VINYL LINER,
FOLLOW STEP 2B.
2a. Install a Flat Washer (A) onto each Threaded Rod. On the left rod, install the Bonding Wire (B).
THE BONDING WIRE IS INSTALLED.
Fig. 13
2b. Install a Sealing Washer (A) onto each Threaded Stud. The stainless steel side of washer MUST face out. Install a
Flat Washer (B) onto each stud. On the left stud, install the Bonding Wire (C).
WIRE IS INSTALLED.
seated against the pool wall. Tighten another half turn. DO NOT OVERTIGHTEN (Fig. 14).
Fig. 14
15
Secure Hydrostride using Lock Washers (C) and Jam Nuts (D) (Fig. 13).
C
D
Secure Hydrostride using Lock Washers (D) and Jam Nuts (E). Tighten nuts until the unit is fully
C
D
E
A
B
A
B
IT IS CRITICAL THAT
IT IS CRITICAL THAT THE BONDING
