  • Page 1 ENDLESS POOL S HYDROSTRIDE ® ™ INSTALL ATION INSTRUCTIONS...

  • Page 2: Installation Instructions Table Of Contents Warnings And Safety Information

    WARNING: Before each use, examine the treadmill for damage or signs of wear. Do not use the product if found in this condition. Contact Endless Pools Customer Service. WARNING: This product contains moving parts. Moving parts and other features of this product can be danger- ous.
  • Page 3 Endless Pools Hydrostride Installation ™ ® Other Important Safety Instructions WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely super- vised at all times. AVERTISSEMENT: Pour réduire le risque de blessure, ne permettez pas aux enfants d’utiliser ce produit à moins qu’ils ne soient surveillés de près en tout temps.
  • Page 4 Endless Pools Hydrostride Installation ™ ® DANGER: RISK OF ELECTRIC SHOCK: Install at least 5 feet (1.5 m) from all metal surfaces. As an alternative, a spa may be installed within 5 feet of metal surfaces if each metal surface is permanently connected by a minimum 8 AWG (8.4 mm2) solid copper conductor to the wire...
  • Page 5 Endless Pools Hydrostride Installation ™ ® WARNING: PREGNANT OR POSSIBLY PREGNANT WOMEN SHOULD CONSULT A PHYSICIAN BEFORE USING A SPA OR HOT TUB. AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIRMÉE OU NON, DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE CUVE DE RELAXATION.

  • Page 6: Table Of Contents

    Hydrostride & Grab Bar Mounting Kit Installation Using The Hydrostride ......57 – Steel Panel Pool With Vinyl Liner ....31 Bonding The Hydrostride .

  • Page 7: Choosing A Location

    Hydrostride The Hydrostride can fit into virtually any swimming pool. For optimal use, it’s recommended that the Hydrostride is installed no closer than 18" (46cm) to any adjacent wall. In addition, 18" (46cm) of clearance is recommended at the rear of the Hydrostride.

  • Page 8: Receiving The Hydrostride

    ® If installing the optional Fastlane Pro in conjunction with the Hydrostride, 24" (61cm) of clearance is required on each side of the swim unit to any adjacent wall. In addition, the water depth where the swim unit is installed MUST be a minimum of 46"...

  • Page 9: Hydrostride & Grab Bar Mounting Kit Installation - Gunite Pool

    HYDROSTRIDE & GRAB BAR MOUNTING KIT INSTALLATION – GUNITE POOL A The Hydrostride and grab bar for the Hydrostride attach directly to the pool wall with the use of a wall mounting bracket. The mounting brackets are to be embedded into the pool wall as shown in Figures 4A.1. & 4A.2. The placement of the brack- ets on the pool wall is CRITICAL.
  • Page 10 ® Both the Hydrostride and grab bar mounting brackets will be tied to the rebar grid of the pool prior to the gunite applica- tion. Additionally, the threaded rods of the brackets will be tied to the bonding grid of the pool using the provided bonding clamps and a # 8 solid copper wire (not provided by Endless Pools).
  • Page 11 Endless Pools Hydrostride Installation ™ ® Hydrostride Mounting Kit – Gunite Pool Grab Bar Mounting Kit – Gunite Pool Qty Description Description Wall Mounting Bracket Wall Mounting Bracket 2” (51mm) SPG x 1-1/2” (38mm) FSlip PVC Bushing Reducer 3/8” (9,5mm) Threaded Rod 2”...
  • Page 12 (Installed prior to gunite application) Fig. 4A.4 1. Starting with the Hydrostride mounting bracket, ensure the threaded rods extend approximately 1-1/2" (38mm) past the couplings. The threaded rods can be adjusted by loosening the jam nuts (Fig. 4A.5). Jam Nut/Washer Jam Nut/Washer 1-1/2"...
  • Page 13 ® 2. Loosely position the Hydrostride mounting bracket into the rebar grid of the pool so that the bottom edge of the bracket is 5-1/4" (13,3cm) above the expected finished pool floor. The thickness of the gunite and finish coat MUST be accounted for when positioning the bracket.
  • Page 14 Fig. 4A.7 4. The threaded rods attached to BOTH the Hydrostride and grab bar mounting brackets MUST be tied into the pool’s bond- ing grid. Secure a bonding clamp onto each threaded rod (4 total). Attach a # 8 solid copper wire to each bonding clamp.
  • Page 15 5.1 A mounting template has been provided to ensure proper placement of the Hydrostride mounting bracket during the gunite application. If the Hydrostride is to be recessed into the pool floor, skip to steps 5.4 – 5.9. Loosely hang the mounting template from the threaded rods of the Hydrostride mounting bracket, making sure the rods are at the top of the slotted holes in the template (Fig.
  • Page 16 The coupling nuts of the grab bar mounting bracket should be flush with the finished pool wall, leaving the sacrificial bolts just inside the finished pool wall for removal (Fig. 4A.11). Proceed to Section 6: Hydrostride Assem- bly.
  • Page 17 ® 5.4 If the Hydrostride is to be recessed into the pool floor, it’s recommended to construct a mold using plywood, lumber, and the provided mounting template. The intent of the mold is to form the recessed area in the pool floor during the applica- tion of the gunite as shown in Figure 4A.12.
  • Page 18 Fig. 4A.14 5.7 Position and loosely hang the mold from the threaded rods of the Hydrostride mounting bracket, making sure the rods are at the top of the slotted holes in the mounting template. The bottom of the template represents the finished pool floor (gunite and finish coat).
  • Page 19 Endless Pools Hydrostride Installation ™ ® 5.8 Adjust the position of the mold on the threaded rods so that the PVC couplings extend a maximum of 1/2” (12,7mm) past the front of the mounting template. Use the additional flat washers and jam nuts to secure the mold in place during the gunite application.
  • Page 20 The recessed area should be sealed with an appropriate hydraulic cement without adding height to the floor. Again, the PVC couplings of the Hydrostride mounting bracket should extend a maximum of 1/2” (12,7mm) into the finished pool. The coupling nuts of the grab bar mounting bracket should be flush with the finished pool wall, leaving the sacrificial bolts just inside the finished pool wall for removal (Fig.

  • Page 21: Hydrostride & Grab Bar Mounting Kit Installation - Gunite Pool With Vinyl Liner

    HYDROSTRIDE & GRAB BAR MOUNTING KIT INSTALLATION – GUNITE POOL WITH VINYL LINER The Hydrostride and grab bar for the Hydrostride attach directly to the pool wall with the use of a wall mounting bracket. The mounting brackets are to be embedded into the pool wall as shown in Figures 4B.1. & 4B.2. The placement of the brackets on the pool wall is CRITICAL.
  • Page 22 Additionally, the threaded rods of the brackets will be tied to the bonding grid of the pool using the provided bonding clamps and a # 8 solid copper wire (not provided by Endless Pools). Flexible PVC pipe is to be glued into the fittings on the backside of the Hydrostride bracket which will serve as conduits for the hydraulic lines.
  • Page 23 Endless Pools Hydrostride Installation ™ ® Hydrostride & Grab Bar Mounting Kit Parts List (Refer to Figures 4B.3 & 4B.4): Hydrostride Mounting Kit – Gunite Pool With Vinyl Liner Grab Bar Mounting Kit – Gunite Pool With Vinyl Liner Description Description...
  • Page 24 Endless Pools Hydrostride Installation ™ ® Hydrostride Mounting Kit Detail Jam Nut (backside of bracket) Coupling Nut (backside of bracket) Rubber Washer Sealing Washer 1-1/2" (38mm) MPT x FSlip Adapter Hex Head Bolt Bonding Thru-Wall Screw Lock Nut Bonding Mounting...
  • Page 25 Installation ™ ® 1. Install the star thru-wall fittings in the openings of the Hydrostride mounting bracket making sure the holes in the fittings are oriented in the 12, 3, 6, and 9 o’clock positions (Fig. 4B.5). Thru-Wall Lock Nut...
  • Page 26 Fig. 4B.7 4. Loosely position the Hydrostride mounting bracket into the rebar grid of the pool so that the bottom edge of the bracket is 6" (15,24cm) above the expected finished pool floor. The thickness of the gunite and pool liner MUST be accounted for when positioning the bracket.
  • Page 27 5. The location of the Hydraulic Power Unit should be determined at this point in the installation. Unroll lengths of 1-1/2" (38mm) flexible PVC pipe from the back of the Hydrostride mounting bracket to the Power Unit. The conduit run MUST travel above the pool’s waterline.
  • Page 28 ® 6. The threaded rods attached to BOTH the Hydrostride and grab bar mounting brackets MUST be tied into the pool’s bond- ing grid. Secure a bonding clamp onto each threaded rod (4 total). Attach a # 8 solid copper wire to each bonding clamp.
  • Page 29 The gunite should be shot up to the back of the mounting template which should make the Hydrostride mounting bracket and coupling nuts of the grab bar mounting bracket flush with the finished pool wall, leaving the sacrificial bolts just inside the finished pool wall.
  • Page 30 Endless Pools Hydrostride Installation ™ ® 9. After removing the mounting template and sacrificial bolts from the grab bar mounting bracket, the pool liner should be installed. Once installed, add approximately 3" (7,6cm) of water to add weight to the liner before cutting holes for the fittings and mounting holes.
  • Page 31 12. At the top of the pool wall, locate the coupling nuts behind the liner for the grab bar. Cut or poke out the holes in the liner using the inside of the coupling nut as a template (Fig. 4B.16). After all holes have been cut in the liner, proceed to Section 6: Hydrostride Assembly. Top of pool...

  • Page 32: Hydrostride & Grab Bar Mounting Kit Installation

    – STEEL PANEL POOL WITH VINYL LINER The Hydrostride and grab bar for the Hydrostride attach directly to the steel pool wall with the use of a wall mounting kit. The mounting kits include mounting brackets which are to be temporarily adhered to the pool wall with duct tape and used as templates to mark the mounting locations for the Hydrostride and grab bar as shown in Figure 4C.1.
  • Page 33 Hydrostride Installation ™ ® Hydrostride & Grab Bar Mounting Kit Parts List: Hydrostride Mounting Kit – Steel Panel Pool With Vinyl Liner Grab Bar Mounting Kit – Steel Panel Pool With Vinyl Liner Description Description Wall Mounting Bracket (Template) Wall Mounting Bracket (Template) 1-1/2”...
  • Page 34 Cut out the star openings using a 3" (76mm) hole saw at the center point of the traced outline. For the Hydrostride and grab bar mounting holes, drill a pilot hole in the middle of each hole. Drill out the holes using a 1/2"...
  • Page 35 Endless Pools Hydrostride Installation ™ ® 3. Thread the rivet nut fully onto the rivet nut tool (Fig. 4C.4). Rivet Nut Rivet Nut Tool Fig. 4C.4 4. From the inside of the pool, insert the rivet nut into the mounting hole in the pool wall. A 7/8" (22mm) wrench and 11/16"...
  • Page 36 6. The location of the Hydraulic Power Unit should be determined at this point in the installation. Unroll lengths of 1-1/2" (38mm) flexible PVC pipe from the back of the Hydrostride mounting bracket to the Power Unit. The conduit run MUST travel above the pool’s waterline.
  • Page 37 Endless Pools Hydrostride Installation ™ ® Apply Teflon tape to the threads of the MPT x FSlip adapters and thread them into the back of the thru-wall fittings. Glue the lengths of flexible pipe into the adapters (Fig. 4C.8). Hydraulic...
  • Page 38 Endless Pools Hydrostride Installation ™ ® 8. The pool liner should be installed at this time. Once installed, add approximately 3" (7,6cm) of water to add weight to the liner before cutting holes for the fittings and mounting holes. At the bottom of the pool wall, locate the thru-wall fittings behind the liner. Position the thru-wall faceplates against the lin- er making sure the holes in the faceplate align with the holes in the thru-wall fitting.
  • Page 39 11. At the top of the pool wall, locate the rivet nuts behind the liner for the grab bar. Cut or poke out the holes in the liner using the inside of the rivet nut as a template (Fig. 4C.13). After all holes have been cut in the liner, proceed to Section 6: Hydrostride Assembly. Top of pool...

  • Page 40: Junction Box

    It is at the junction box where a step up to the 1/2" (12,7mm) run hose occurs. The hydraulic hose from the Hydrostride to the junction box is 3/8" (9,5mm) and the run hose from the junction box to the hydraulic power unit is 1/2"...

  • Page 41: Hydrostride Assembly

    Endless Pools Hydrostride Installation ™ ® Section 6: HYDROSTRIDE ASSEMBLY Parts List: The Hydrostride Installation Kit includes the following: Description Description Bottom Plate Wall Mount Grab Bar Standoff Side Deck Lower Cover End Cover (Left & Right) Hose Clamp 3/4” (19mm) Phillips Truss Head Screw 1”...
  • Page 42 Endless Pools Hydrostride Installation ™ ® 2. Attach the bottom plates to the underside of the treadmill body using the 1" (25mm) Phillips truss head screws. After this step has been completed, carefully lower the treadmill to the ground (Fig. 6.2).
  • Page 43 Endless Pools Hydrostride Installation ™ ® 4. Attach the side decks to the treadmill body using the 1" (25mm) Phillips truss head screws. If installing the treadmill in a recessed concrete pit for a flush appearance, the screw holes at the rear of the side deck can be countersunk and 1" (25mm) flat head screws can be used (Fig.
  • Page 44 Endless Pools Hydrostride Installation ™ ® 6. Route the hydraulic hoses through the standoff as shown in Figure 6.6. Use the hose clamps provided to secure the hoses to the standoff. Attached hose clamps with 3/4" (19mm) Phillips truss head screws...

  • Page 45: Hydrostride & Grab Bar Installation - Gunite Pool

    ® 8. If the Hydrostride is being installed into a pool using a salt-chlorine generator for sanitation, a sacrificial zinc anode MUST be installed to combat the corrosive nature of the salt. Secure the zinc anode to the left end cover using the provide machine screw, washer, and nut (Fig.
  • Page 46 Threaded Mounting Hole Fig. 7A.2 3. Install a 3/8" (9,5mm) flat washer, lock washer and jam nut onto each threaded rod to secure the Hydrostride to the pool wall (Fig. 7A.3). Jam Nut Lock Washer Flat Washer...
  • Page 47 ® 4. The next step is bonding the Hydrostride. This is a CRITICAL step. If a sacrificial zinc anode is installed skip to step 5. Attach the stainless steel bond wire that’s pre-attached to the Hydrostride (front left corner) to the threaded rod. Secure the bond wire with the additional jam nut provided (Fig.
  • Page 48 Endless Pools Hydrostride Installation ™ ® 6. Attach the lower cover to the Hydrostride body using the 1" (25mm) Phillips truss head screws (Fig. 7A.6). 1" (25mm) Phillips Truss Head Screw Lower Cover Fig. 7A.6 7. Align the mounting holes in the flanges of the grab bar with the coupling nuts that are embedded into the pool wall. Attach the grab bar to the pool wall using the 3/4"...

  • Page 49: Hydrostride & Grab Bar Installation - Gunite/Steel Panel Pool With Vinyl Liner

    Hydrostride Installation ™ ® 8. If a Fastlane is being installed in conjunction with the Hydrostride, it should be installed at this time. Refer to the Fastlane Owner’s Manual for detailed information (Fig. 7A.8). Fig. 7A.8 Section 7B: HYDROSTRIDE AND GRAB BAR INSTALLATION – GUNITE/STEEL PANEL POOL WITH VINYL LINER 1.
  • Page 50 Fig. 7B.2 3. Align the mounting holes in the standoff with the mounting holes in the pool wall. Secure the Hydrostride using the 1-1/4” (32mm) hex head bolts and washers. The hex head bolt with the tapped hole (bonding bolt) MUST be installed on the left side.
  • Page 51 ® 4. The next step is bonding the Hydrostride. This is a CRITICAL step. If a sacrificial anode is installed skip to step 5. Thread the 1/4" (6,3mm) machine screw into the hex head bolt on the left side of the treadmill. Attach the stainless steel bond wire that’s pre-attached to the treadmill (front left corner) to the machine screw before tightening the screw (Fig.
  • Page 52 Endless Pools Hydrostride Installation ™ ® 6. Attach the lower cover to the treadmill body using the 1" (25mm) Phillips truss head screws (Fig. 7B.6). 1" (25mm) Phillips Truss Head Screw Lower Cover Fig. 7B.6 7. Apply silicone around the front and back of the grab bar mounting holes. Align the mounting holes in the flanges of the grab bar with the mounting holes that are behind the liner on the pool wall.

  • Page 53: Installation Of The Hydraulic Power Unit

    Hydrostride Installation ™ ® 8. If a Fastlane is being installed in conjunction with the Hydrostride, it should be installed at this time. Refer to the Fastlane Owner’s Manual for detailed information (Fig. 7B.8). Fig. 7B.8 Section 8: INSTALLATION OF THE HYDRAULIC POWER UNIT The hydraulic power unit should be placed on a flat, level surface.
  • Page 54 Endless Pools Hydrostride Installation ™ ® 1. Carefully remove the power unit from the packaging. This should be done with two people. The power unit is very heavy. To remove the power unit open box top flaps, lay box on its side, open box bottom flaps, and slide the power unit out of the box sideways on the bottom foam.

  • Page 55: Electrical Requirements For The United States (60Hz)

    ELECTRICAL REQUIREMENTS FOR THE UNITED STATES (60HZ) (and countries with similar electrical requirements) The Endless Pools Hydrostride is ETL marked and CE listed. A Ground Fault Circuit Interrupter (GFCI) is required for this product. A GFCI is a device that shuts off an electrical circuit when it detects that electricity is flowing along an unintended path.

  • Page 56: Electrical Requirements For The Uk (50Hz)

    ELECTRICAL REQUIREMENTS FOR THE UNITED KINGDOM (50HZ) (and countries with similar electrical requirements) The Endless Pools Hydrostride is ETL marked and CE listed. A Residual Current Device (RCD) is required for this product. An RCD is a device that shuts off an electrical circuit when it detects that electricity is flowing along an unintended path.

  • Page 57: Equipment Start Up

    (-8 female JIC x –6 male JIC) that were provided in the Hydrostride installation kit must be used. If a junction box was used and the 1/2" (12,7mm) run hoses are to be attached to the power unit, then these hoses will connect directly to the appropriate connections on the power unit (without the use of the hydraulic hose adapters).

  • Page 58: Using The Hydrostride

    5 gallon (19L) bucket used to fill the power unit reservoir. 4. Turn on the Hydrostride, making sure to hold the hoses firmly over the bucket. Press and hold the faster button. The return- ing hydraulic fluid will flow into the bucket. The system will automatically shut off when the float level switch inside the fluid reservoir is tripped.

  • Page 59: Bonding The Hydrostride

    All Hydrostride shipments include bonding hardware. When installing the Hydrostride in a gunite pool OR a gunite pool with a vinyl liner, bonding clamps are to be attached to each threaded rod of the Hydrostride and grab bar mounting brackets which are typically tied to the rebar grid of the pool.
  • Page 60 Hydraulic Power Unit and power unit controller MUST be incorporated into the pool’ s bonding grid with the use of #8 solid copper wire. This is typically done by bonding the Endless Pools equipment to the existing pool equipment (pump, heater, etc.) that’...

  • Page 61: Maintenance

    Cathodic Protection Maintenance (Salt-Chlorine Pools ONLY) Endless Pools has provided a sacrificial zinc anode to draw any corrosion to itself and away from the Hydrostride. To maxi- mize the life span of Hydrostride, it is imperative that the Hydrostride be properly bonded and the sacrificial zinc anode be replaced after it has given up half its mass.
  • Page 62 Endless Pools • 1601 Dutton Mill Rd • Aston, PA 19014-2931 D12001 0620 800-910-2714 US • 610-497-8693 fax • www.myendlesspool.com © 2020 Wellness Marketing Corporation...
