3. Basic circuit

Circuit Configuration

The standard circuit for operating a rotary actuator with an air filter, regulator, solenoid valve
and speed controller is shown in Fig. 1 below.
エアフ
ィルタ

Recommended models

Recommended models for the standard circuit in Fig. 1 are shown in Table 1 below.
Size
Note) The speed controllers must be used in a meter-out control.
ﾐｽﾄ
レギュ
ｾﾊﾟﾚｰﾀ
レータ
Solenoid valve (CV)
10
0.05
15
20
30 0.1 to 0.2
40
(Do not use a speed controller for slow speed.)
ｽﾋﾟｰﾄﾞ・
ｺﾝﾄﾛｰﾗ
電磁弁
Fig.1
Table 1
Speed Controller
AS-M5
AS-M3(Type270°)
AS-M5
27
ロータリ･
アクチュ
エータ
Tubing
φ4/ φ2.5
φ6/ φ4
φ4/ φ2.5
φ6/ φ4
