Auto Switch Proper Mounting Position

Solid state auto switch
Size
10
15
20
30
40

Operating Angle and Hysteresis Angle

Solid state auto switch
Size
Operating angle (θm) Hysteresis angle
10 36 o
o
15 36
20 20 o
o
30 20
o
40 20
(mm)
D-M9□
A
6
6
6
6
6
D-M9□
5 o
o
5
5 o
o
5
o
5
Note) Since the figures in the table on the left are
provided as a guideline only, they cannot
be guaranteed. Adjust the auto switch after
confirming the operating conditions in the
actual setting.
Proper tightening torque: 0.05 to 0.15 [N·m]
