2. Internal Construction and Description of Individual Parts
al Construction and Description of Individual Parts
部
Single Vane (90°,180°Specifications: Size 10, 15)
Component Parts
No.
10
11
Description
1
Body (A)
2
Body (B)
3
Vane shaft
4
Stopper
5
Stopper for 90
o
6
Holding rubber
7
Stopper seal
8
Back-up ring
9
Bearing
O-ring
Hexagon socket head cap screw
Material
Aluminum alloy
Aluminum alloy
Stainless steel
Resin
Resin
NBR
NBR
Stainless steel
Bearing steel
NBR
Chrome molybdenum steel
20
Note
Painted
Painted
For 90
o
For 90
o
Special seal
Special screw
