- Page 1 Doc. No.JCRB-OM00003-D PRODUCT NAME ROTARY ACTUATOR Standard Type MODEL / Series / Product Number C＊RB＊10 to 40-＊...
-
Page 2: Table Of Contents
Contents Safety Instructions ........................2 Rotary Actuators Precautions ....................4 Auto Switches Precautions ...................... 11 1. Product Description ......................17 2. Internal Construction and Description of Individual Parts ........... 20 Single Vane (90°,180°Specifications: Size 10, 15) Single Vane (90°,180°Specifications: Size 20, 30, 40) ............21 Single Vane (270°Specifications) .................. -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
-
Page 5: Rotary Actuators Precautions
Design / Selection Warning (1) Confirm the specifications. Products represented in this catalog are designed only for use in compressed air systems. Do not operate at pressures or temperatures, etc., beyond the range of specifications, as this can cause damage or malfunction. (Refer to the specifications.) We do not guarantee against any damage if the product is used outside of the specification range. - Page 6 (12) Select a speed within the product’s allowable energy value. If the kinetic energy of the load exceeds the allowable value, it could damage the product, and cause a hazard to humans, or damage the machinery and equipment. (13) Provide a shock absorber if the kinetic energy that is applied to the product exceeds the allowable value.
- Page 7 Design / Mounting Warning (1) Operation manual Install the product and operate it only after reading the operation manual carefully and understanding its contents. Also, keep the manual in a location where it can be referred to as necessary. (2) Ensure sufficient space for maintenance activities. When installing the products, allow access for maintenance.
- Page 8 Precautions when using external stoppers Be sure to install external stoppers in the proper places. Installation in the wrong place can result in equipment breakage, which could damage other equipment or cause human injury. Correct position Incorrect position Incorrect position Install the stopper at a sufficient The external stopper becomes a If an external stopper is installed...
- Page 9 Caution (1) Do not use organic solvent to wipe the area of the name plate that shows the model. It will erase what is indicated on the name plate. (2) Do not hit the output shaft by securing the body or hit the body by securing the output shaft.
- Page 10 Speed and Cushion Adjustment Warning (1) To make a speed adjustment, gradually adjust starting from the low speed end. If the speed adjustment is performed from the high speed end, it could damage the product. As a result, it could pose a hazard to humans and damage the machinery and equipment. For products with shock absorbers, when the shock absorber stops moving before reaching the stroke end by using a stopper mechanism with the objective of shortening tact time, be sure the shock absorber is stopped in a position where it has adequately absorbed the...
- Page 11 (3) Take measures to ensure air quality, such as by installing an aftercooler, air dryer, or water separator. Compressed air that contains a large amount of moisture can cause malfunction of pneumatic equipment such as rotary actuator. Therefore, take appropriate measures to ensure air quality, such as by providing an aftercooler, air dryer, or water separator.
-
Page 12: Auto Switches Precautions
Auto Switches Precautions Design / Selection Warning (1) Confirm the specifications. If the product is used with excess load applied or beyond the specification range, this may cause the product to break or malfunction. We do not guarantee against any damage if the product is used outside of the specification range. - Page 13 (3) Do not use a load that generates surge voltage. If a surge voltage is generated, discharge may be generated at the contact, possibly reducing the product life. <Reed> Use an auto switch with built-in contact protection circuit or use a contact protection box. <Solid state>...
- Page 14 (8) Use the rotary actuator and auto switch in proper combination. The auto switch is pre-adjusted to operate properly for an auto-switch-capable SMC rotary actuator. If the auto switch is mounted improperly, used for another brand of rotary actuator or used after changing the machine installation, the auto switch may not operate properly.
- Page 15 (4) Be certain to connect the load before power is applied. <2-wire type> If the power is turned ON when an auto switch is not connected to a load, the auto switch will be instantly damaged because of excess current (Short circuit). In addition, when using a commercially available checker, etc., to perform an acceptance inspection or check the operation of a 2-wire auto switch, be sure to confirm the wiring method of the checker beforehand and make sure to connect the terminal with a built-in load (IN, etc.)
- Page 16 (2) Do not use in an environment where the auto switch will be continually exposed to water. Although auto switches satisfy IEC standard IP67 construction, do not use auto switches in applications where they will be continually exposed to water splash or spray. This may cause improper insulation or malfunction.
- Page 17 Caution (1) Perform the following maintenance and inspection periodically in order to prevent possible danger due to unexpected auto switch malfunction. 1) Secure and tighten auto switch mounting screws. If screws become loose or the mounting position is dislocated, retighten them after readjusting the mounting position.
-
Page 18: Product Description
1. Product Description This manual describes the operation of the vane type compact rotary actuator, CRB Series. Confirm the operating conditions such as load size (inertial moment), rotating time, and the product specifications before using this product. How to Order With auto switch Built-in auto switch magnet ②... - Page 19 Double Vane Specifications Size о о о о Rotating angle range о о о +/-2 о +/-2.5 Fluid Air (Non-lube) Proof pressure [MPa] 1.05 Fluid temperature [ 5 to 60 Max. operating pressure [MPa] Min. operating pressure [MPa] Speed adjustable range [s / 90 (Note 3) 0.05 to 0.5 0.1 to 0.5...
- Page 20 Chamfered Position and Rotation Range: Top View from Long Shaft Side Chamfered positions shown below illustrate the conditions of actuators when B port is pressurized. ・Single vane ・Double vane For 90° For 100° Note) Note) Chamfer Chamfer (When B port is (When B port is pressurized) pressurized)
-
Page 21: Internal Construction And Description Of Individual Parts
2. Internal Construction and Description of Individual Parts al Construction and Description of Individual Parts 部 Single Vane (90°,180°Specifications: Size 10, 15) Component Parts Description Material Note Body (A) Aluminum alloy Painted Body (B) Aluminum alloy Painted Vane shaft Stainless steel Stopper Resin Stopper for 90... -
Page 22: Single Vane (90°,180°Specifications: Size 20, 30, 40)
部 Single Vane (90°,180°Specifications: Size 20, 30, 40) Component Parts Description Material Note Body (A) Aluminum alloy Painted Body (B) Aluminum alloy Painted Vane shaft Stainless steel * Stopper Resin Stopper for 90 Resin For 90 Holding rubber For 90 Stopper seal Special seal Back-up ring... -
Page 23: Single Vane (270°Specifications)
部 Single Vane (270°Specifications) * The left figures show the position of the ports during rotation. Component Parts Description Material Note Body (A) Aluminum alloy Painted Body (B) Aluminum alloy Painted Vane shaft Stainless steel * Stopper Resin Stopper seal Special seal Stopper pin Bearing steel... -
Page 24: Double Vane (Size 10)
Double Vane (Size 10) For 90° For 100° * The left figures show the position of the ports during rotation. Component Parts Description Material Note Body (A) Aluminum alloy Painted Body (B) Aluminum alloy Painted Vane shaft Chrome molybdenum steel Stopper Resin Stopper seal... -
Page 25: Double Vane (Size 15,20,30,40)
Double Vane (Size 15,20,30,40) For 100° For 90° ⑪ F or size 40 * The left figures show the position of the ports during rotation. Component Parts Description Material Note Body (A) Aluminum alloy Painted Body (B) Aluminum alloy Painted Vane shaft Stainless steel * Stopper... -
Page 26: With Auto Switch (Single Vane: 90°,180°Specifications)
With Auto Switch (Single Vane: 90°,180°Specifications) * For models with auto switch, only 90° and 180° can be selected. Note: The single vane 270° and double vane specifications do not have this structure. For details, please refer to the instruction manual No. JCRB-OM0002. For details, please refer to the instruction manual No. -
Page 27: Auto Switch Proper Mounting Position
Auto Switch Proper Mounting Position (mm) Solid state auto switch D-M9□ Size Operating Angle and Hysteresis Angle Solid state auto switch Size D-M9□ Operating angle (θm) Hysteresis angle Note) Since the figures in the table on the left are provided as a guideline only, they cannot be guaranteed. -
Page 28: Basic Circuit
3. Basic circuit Circuit Configuration The standard circuit for operating a rotary actuator with an air filter, regulator, solenoid valve and speed controller is shown in Fig. 1 below. ロータリ･ ﾐｽﾄ レギュ ｽﾋﾟｰﾄﾞ・ エアフ アクチュ ｾﾊﾟﾚｰﾀ レータ ｺﾝﾄﾛｰﾗ ィルタ エータ 電磁弁... -
Page 29: Setting
4. Setting Warning Limit load to the shaft (1) Although static loads shown in Table 2 are allowable, avoid applying load directly to the shaft. Table 2 Allowable shaft load Load direction Size Fs [N] Fr [N] M [N-m] 14.7 0.13 14.7 0.17... -
Page 30: How To Mount Loads
How to Mount Loads How to connect a load directly to a single flat shaft. To secure the load, select a bolt of an appropriate size from those listed in tables 3 and 4 by taking the shaft’s single flat bearing stress strength into consideration. Table 3 Directly Fixed with Bolts (Refer to Fig. -
Page 31: Adjusting The Rotating Angle
Warning Adjusting the rotating angle Do not apply a load when adjusting the rotating angle. For size 20, 30 and 40, the rotation range can be set as shown in Fig.11 and 12 by adjusting the adjustment bolt whilst supplying air to the opposite port. *A Box wrench may be required to adjust the angle depending on the usage environment. -
Page 32: Operating Environment
Warning Operating environment Do not use in environments where there is a danger of corrosion. Refer to "Internal Construction and Components" on pages 4 to 6 for materials used for the rotary actuator. Never use this product in dusty locations or where water, oil, etc., splash on the equipment. -
Page 33: Setting Of Rotation Time
5. Setting of Rotation Time Even if the torque - required by the load in the rotation movement is small, the shaft and/or internal parts could become damaged depending on the inertia of the load. Therefore, select an appropriate model for your application by taking the load’s moment of inertia, kinetic energy, and rotation time into consideration. - Page 34 (3) Moment of inertia of each style can be found with the calculation formula shown below. How to read Graph 1. Example 1) When there are constraints for the moment of inertia of load and rotation time. From “Graph 1”, to operate at the load moment of inertia 1 x 10–4 kg·m2 and at the rotation time setting of 0.3 / 90°, the model will be CRB□30.
-
Page 35: Kinetic Energy
Kinetic energy Allowable kinetic energy is shown in Table 7. Table 7 Unit (J) Allowable kinetic energy Size Single Vane Double Vane 0.00015 0.0003 0.001 0.0012 0.003 0.0033 0.02 0.04 Since the rotary actuator reaches the rotation end in the middle of acceleration, terminal acceleration "ω"... -
Page 36: Eternal Stopper
External stopper If the kinetic energy - generated by the load exceeds the actuator’s threshold value, an external dampening function must be provided to absorb the energy. The figure below shows the correct installation of external stopper. As a rotary actuator itself has a slight angular error due to the construction, use an external stopper when accurate positioning is required. -
Page 37: Maintenance And Inspection
6. Maintenance and Inspection ［Precautions］ a. Disassembling the product will void SMC’s warranty. If disassembly is really necessary it is recommended to fully understand the internal construction before disassembling the products. b. Do not damage the seals when reassembling the product. Be sure to add grease to all the seals and sliding surfaces of the bodies and vane shaft. -
Page 38: Single Vane (90°,180° Specifications: Size 20, 30,40)
Single Vane (90°,180° Specifications: Size 20, 30,40) 90° specification 180° specification ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product. (As operation failure is caused by an increase in the internal leakage in most of the cases, the speed controller needs to be readjusted. -
Page 39: Single Vane (270°Specifications)
Single Vane (270°Specifications) ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product. (As operation failure is caused by an increase in the internal leakage in most of the cases, the speed controller needs to be readjusted. -
Page 40: Double Vane (Size 10)
Double Vane (Size 10) ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product. (As operation failure is caused by an increase in the internal leakage in most of the cases, the speed controller needs to be readjusted. -
Page 41: Double Vane (Size 15,20,30,40)
Double Vane (Size 15,20,30,40) ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product. (As operation failure is caused by an increase in the internal leakage in most of the cases, the speed controller needs to be readjusted. -
Page 42: With Auto Switch (Size 20, 30, 40)
With Auto Switch (Size 20, 30, 40) 180° specification 90° specification For CDRB20, 30, 40-90 <Disassembly> 1. Remove the parallel key. (For size 40.) 2. Remove the cross recessed round head screw (18). 3. Remove the cover (14) and magnet holder (15). 4. -
Page 43: Troubleshooting
7. Troubleshooting 8. Notice on Trouble and Troubleshooting Failure Possible causes Countermeasures Use the product within the specified speed The product is not used at a speed within the adjustable range shown in the catalog or range of the stable speed adjustable range. operation manual. - Page 44 Notes for the Troubleshooting shown above Causes of the operation failure due to product life are not shown in the troubleshooting table.
- Page 45 Revision history A : Size 20 and 30 270° specifications added. B : Size 10, 15 and 40 270°specifications added. C : Added note about angle adjustment (P12) D : Double vane specifications added. Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
