SMC Networks CRB2 10 Series Operation Manual

Rotary actuator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Doc.no.CRB2-OM00012-B
PRODUCT NAME
ROTARY ACTUATOR
MODEL / Series / Product Number
CRB2**10 to 40-*S*Z
CRB2**10 to 40-*D*Z

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRB2 10 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks CRB2 10 Series

Summary of Contents for SMC Networks CRB2 10 Series

  • Page 1 Doc.no.CRB2-OM00012-B PRODUCT NAME ROTARY ACTUATOR MODEL / Series / Product Number CRB2**10 to 40-*S*Z CRB2**10 to 40-*D*Z...

  • Page 2: Table Of Contents

    Contents Precautions for Safety 1. Product Description How to Order Specifications Effective torque Chamfer Position and Rotation Range 2. Internal Construction and Description of Individual Parts 3. Basic circuit Circuit Configuration Recommended models 4. Mounting Air Supply Piping Shaft Load Limit Shaft fitting Operating environment 5.

  • Page 3: Precautions For Safety

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5 Design / Selection Warning 1. Confirm the specifications. Products represented in this catalog are designed only for use in compressed air systems. Do not operate at pressures or temperatures, etc., beyond the range of specifications, as this can cause damage or malfunction. (Refer to the specifications.) We do not guarantee against any damage if the product is used outside of the specification range.
  • Page 6 13. Provide a shock absorber if the kinetic energy that is applied to the product exceeds the allowable value. If the product’s kinetic energy exceeds the allowable value, it could damage the product, and cause a hazard to humans, or damage the machinery or equipment. 14.
  • Page 7 Design / Mounting Warning 1. Operation manual Install the product and operate it only after reading the operation manual carefully and understanding its contents. Also, keep the manual in a location where it can be referred to as necessary. 2. Ensure sufficient space for maintenance activities. When installing the products, allow access for maintenance.
  • Page 8 Precautions when Using External Stoppers Be sure to install external stoppers in the proper places. Installation in the wrong place can result in equipment breakage, which could damage other equipment or cause human injury. Correct position Incorrect position Incorrect position Install the stopper at a sufficient The external stopper becomes a If an external stopper is installed...
  • Page 9 Caution 1. Do not use organic solvent to wipe the area of the name plate that shows the model. It will erase what is indicated on the name plate. 2. Do not hit the output shaft by securing the body or hit the body by securing the output shaft. These actions could cause the table to bend or damage the bearing.
  • Page 10 Lubrication Warning 1. This product should be used without lubrication. Although it will operate even if it is lubricated, it could lead to sticking or slipping. Air Supply Warning 1. Type of fluids Use compressed air. 2. When there is a large amount of moisture Compressed air containing a large amount of moisture can cause malfunction of pneumatic equipment.
  • Page 11 Maintenance Warning Perform maintenance inspection according to the procedures indicated in the operation manual. If handled improperly, malfunction and damage of machinery or equipment may occur. Maintenance work If handled improperly, compressed air can be dangerous. Assembly, handling, repair and element replacement of pneumatic systems should be performed by a knowledgeable and experienced person.
  • Page 12 Auto Switches Precautions Design / Selection Warning 1. Confirm the specifications. If the product is used with excess load applied or beyond the specification range, this may cause the product to break or malfunction. We do not guarantee against any damage if the product is used outside of the specification range.
  • Page 13 4. Take precautions when multiple rotary actuator are used close together. When multiple auto switch rotary actuator are used in close proximity, magnetic field interference may cause the auto switches to malfunction. Maintain a minimum separation of 40mm between rotary actuator.
  • Page 14 Mounting / Adjustment Caution 1. Do not drop or bump. Do not drop, bump or apply excessive impacts (300m/s or more for reed auto switches and 1000m/s more for solid state auto switches) while handling. Although the body of the auto switch may not be damaged, the inside of the auto switch could be damaged and cause malfunction.
  • Page 15 beforehand and make sure to connect the terminal with a built-in load (IN, etc.) to the 0 V terminal. (Do not connect the power supply terminal and the ground terminal directly when in a non-load state.) 5. Do not allow short-circuit of loads. <Reed>...
  • Page 16 5. Do not use in an environment where there is excessive impact shock. <Reed> When excessive impact (300m/s or more) is applied to a reed auto switch during operation, the contacts will malfunction and generate or cut off a signal momentarily (1ms or less). If further excessive impact is applied, the reed auto switch may break.
  • Page 17 Maintenance Warning Removal of equipment, and supply/exhaust of compressed air. Before any machinery or equipment is removed, first ensure that the appropriate measures are in place to prevent workpieces from dropping, run-away equipment, etc. Then, cut off the electric power and reduce the pressure in the system to zero.

  • Page 18: Product Description

    1. Product Description This manual describes the operation of the vane type rotary actuator, CRB2Z Series. Confirm the operating conditions such as load size (inertial moment), rotating time, and the product specifications before using this product. How to Order CRB2 B S 20 - 180 S Z Size Mounting style...
  • Page 19 Double Vane Specifications CRB210 CRB215 CRB220 CRB230 CRB2B40 Vane type Double Vane Rotating angle 90,100 Proof pressure MPa 1.05 Fluid temperature 5 to 60 Max. operating pressure MPa Min. operating pressure MPa 0.15 Speed adjustable 0.03 to 0.3 0.04 to 0.3 0.07 to 0.5 range (S/90 Note 2)

  • Page 20: Effective Torque

    Effective torque Chamfering position and rotation range (Parallel key position is shown for the size 40) Note 1) ( ) inside to the dimension is a guide. Note 2) For single vane type, rotation tolerance of 90 degree , 180 degree and 270 degree actuators will be +5 degree / 0 foe size 10 actuators only.

  • Page 21: Internal Construction And Description Of Individual Parts

    2. Internal Construction and Description of Individual Parts Single vane type Component Parts Description Material Notes Body (A) Aluminium die casting Painting Body (B) Aluminium die casting Painting Vane shaft Stainless steel Stopper Resin Stopper Resin Bearing High carbon chromium bearing steel Back-up ring Stainless steel...
  • Page 22 Double Vane Type CRB2BW10-DZ Component Parts No. Description Material Notes No. Description Material Notes Plate Resin Aluminium die Painting Body (A) Hexagon socket Special casting head cap screw screw Aluminium die Painting Body (B) O-ring casting Stopper seal Special seal Vane shaft Carbon steel Gasket...
  • Page 23 CRB2BW15, 20, 30, 40-DZ Component Parts No. Description Material Notes No. Description Material Notes Aluminium die Painting Hexagon socket Special Body (A) casting head cap screw Aluminium die Painting O-ring Body (B) casting Stopper seal Special seal Vane shaft Carbon steel O-ring Size only 40 Stopper...

  • Page 24: Basic Circuit

    3. Basic circuit Circuit Configuration The standard circuit for operating a rotary actuator with an air filter, regulator, solenoid valve and speed controller is shown in Figure. 1 below. Regulator Air filter mist Rotary Speed separator actuator controller Solenoid valve Figure 1 Recommended models Recommended models for the standard circuit in Fig.

  • Page 25: Mounting

    4. Mounting Caution Air Supply (1) The air supplied to the rotary actuator shall be filtered by an SMC air filter and regulated to the specified set pressure by an SMC AR series regulator. (2) This is a non-lube type actuator. Never supply lubricant oil. (3) If lubricant is supplied to the actuator, the grease inside the actuator will be washed away, and this may cause operation failure.

  • Page 26: Shaft Load Limit

    Warning Shaft Load Limit (1) Although static loads shown in Table 2 are allowable, avoid applying load directly to the shaft. Table 2 Allowable Shaft Load Unit: N Load direction Model 14.7 CRB210 14.7 CRB215 19.6 24.5 CRB220 24.5 29.4 CRB230 CRB240 Note) Application point of force "Fr"...

  • Page 27: Operating Environment

    Warning Operating environment Do not use in environments where there is a danger of corrosion. Refer to "Internal Construction and Components" on pages 20 for materials used for the rotary actuator. Never use this product in dusty locations or where water, oil, etc., splash on the equipment. Model Screw L dimension...

  • Page 28: Setting Of Rotation Time

    5. Setting of Rotation Time Even if the torque - required by the load in the rotation movement is small, the shaft and/or internal parts could become damaged depending on the inertia of the load. Therefore, select an appropriate model for your application by taking the load’s moment of inertia, kinetic energy, and rotation time into consideration.
  • Page 29 (3) Moment of inertia of each style can be found with the calculation formula shown below. How to read Graph 1 Example 1. When CRB220 is used under conditions of moment of inertia of a load of 3.5x10-⁵kgm and rotation time of 0.12 seconds to move 90 degrees; Since the intersection of 3.5 x 10-5kgm on the vertical axis and 0.12 seconds on the horizontal axis is below the energy curve, CRB220 can be used.

  • Page 30: Kinetic Energy

    Kinetic energy Allowable kinetic energy of CRB2 series is shown in Table 3. Table 3 Unit (J) With rubber cushion Without rubber cushion Model Single vane Double vane Single vane Double vane ― 0.00015 0.0003 CRB210 0.001 0.0012 0.00025 0.00027 CRB215 0.003 0.0033...

  • Page 31: External Stopper

    External stopper If the kinetic energy - generated by the load exceeds the actuator’s threshold value, an external dampening function must be provided to absorb the energy. The figure below shows the correct installation of external stopper.  As a rotary actuator itself has a slight angular error due to the construction, use an external stopper when accurate positioning is required.

  • Page 32: Maintenance And Inspection

    6. Maintenance and Inspection Single vane type (CRB210, 15, 20, 30) 90S, 90SE 180S, 180SE 270S, 270SE ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product.

  • Page 33: Single Vane Type (For Crb2 40)

    Single vane type (CRB240) 90S, 90SE 180S, 180SE 270S, 270SE ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product. (As operation failure is caused by an increase in the internal leakage in most of the cases, the speed controller needs to be readjusted.

  • Page 34: Double Vane Type (For Crb2 10)

    Double vane type (CRB210) For CRB210-D, DE <Disassembly> 1. Remove the hexagon socket head cap screws (10). 2. Hold either body A (1) or body B (2), and separate the body A and B by pushing the vane shaft (6) out. 3.

  • Page 35: Double Vane Type (For Crb2 10, 15, 20, 30)

    Double vane type (CRB215, 20, 30) 90D, 90DE 100D, 100DE For CRB215, 20, 30-90D, 90DE <Disassembly> 1. Remove the hexagon socket head cap screws (11). 2. Hold either body A (1) or body B (2), and separate the body A and B by pushing the vane shaft (7) out. 3.

  • Page 36: Double Vane Type (For Crb2 40)

    Double vane type (CRB240) 90D, 90DE 100D, 100DE ● Be sure to install an air filter to clean the supply air. ● Do not disassemble the actuator. When disassembling it for an unavoidable reason, follow the procedures below, and prevent dust and/or foreign matter from entering the product. (As operation failure is caused by an increase in the internal leakage in most of the cases, the speed controller needs to be readjusted.

  • Page 37: Troubleshooting

    7. Troubleshooting Failure Possible causes Countermeasures The product is not used at a speed within the Use the product within the specified speed range of the stable speed adjustable range. adjustable range shown in the catalog or operation manual. Increase in the internal leakage due to damage Replace the vane shaft and stopper seals to the internal seal with foreign matter, drainage, with new ones.

  • Page 38: Notice On Trouble And Troubleshooting

    Notes for the Troubleshooting shown above Causes of the operation failure due to product life are not shown in the troubleshooting table.
  • Page 39 Revision history B: Correction to "Safety Precautions" Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
