Single Vane (90°,180°Specifications: Size 20, 30, 40)
Component Parts
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
* The material is chrome molybdenum steel for sizes 30 and 40.
Description
Body (A)
Body (B)
Vane shaft
Stopper
Stopper for 90 o
Holding rubber
Stopper seal
Back-up ring
Bearing
O-ring
Seal washer
Adjustment bolt
Hexagon nut
Hexagon socket head cap screw
Parallel key
Material
Aluminum alloy
Aluminum alloy
Stainless steel *
Resin
Resin
NBR
NBR
Stainless steel
Bearing steel
NBR
NBR
Chrome molybdenum steel
Steel wire
Chrome molybdenum steel
Carbon steel
21
Note
Painted
Painted
For 90 o
o
For 90
Special seal
Special screw
For size 40
B
