Creating Virtual Network Configurations Offline

2-5-1

Overview

2-5 Creating Virtual Network Configurations Offline
2-5-1 Overview
For a DeviceNet, CompoNet, or CompoWay/F network, the network configuration can
be created offline, the component parameters can be set, and both the configuration
and parameters can be saved in a network configuration file even before the network
has been installed.
All of the component parameters on a network can be downloaded to the actual
components from a previously saved network configuration file after the network has
been installed.
2-5-2

Procedure

CompoWay/F Networks
1. Offline, select Insert
2. Select CompoWay/F and click the Next Button.
3. Enter the name of the network and click the Finish Button.
4. Select a component from the CPS Tab Page in the Component List Window and
drag and drop it in the Network Configuration Window.
2-34
−
Network. The Network/Component Settings Wizard will be
displayed.
