RLS-50100V 3.x.x (xxxx/xx/xx)
Please adjust the mounting position.
Next
【Horizontal detection area】
Tilt angle adjustment
Roll angle adjustment
?
1-6. Adjust the mounting position.
Adjust the mounting position while checking
the camera image.
Refer to the following pages for the procedure.
Adjusting with image checking
Laser detection line
5
【Vertical detection area】
Tilt angle adjustment
Roll angle adjustment
1. Initial configuration
