Record - Optex REDSCAN Pro RLS-50100V Settings Manual

RLS-50100V 3.x.x (xxxx/xx/xx)
Apply settings
Detection range

Record

Detection profile 1
Detection profile 2
Recording time
Input
Pre-alarm record time (sec.)
Event code
Laser settings
Post-alarm record time (sec.)
Camera settings
Trigger
ONVIF media profile
View
Event log
Record
Play
Date and Time
Network
Security
Maintenance
Information
(Bold letters = advanced settings)
Save
2
1
MO A1 B1 A11
A21 A22 B11 B12
B22
DQ AR AM TR
TA
5-6. Event log
5-6-1. Record
You can save the camera image by using the set R.E.C.
?
(REDSCAN Event Code. See list below) as a trigger.
You can set the Pre/Post recording time and the trigger
to start recording.
You can save up to 500 logs.
Recording time
Pre-alarm record time (sec.)
Post-alarm record time (sec.)
Trigger
A12
[ MO, A1, A11, A12, A21, A22, B1, B11, B12,
B21
B21, B22, DQ, AR, AM, TR, SO, TA ]
SO
R.E.C. (REDSCAN Event Code)
A1, A11, A12 .... B1, B11, B12 .....: Zone alarm
AM: Anti-Masking
DQ: Environmental Disqualification
MO: Master Alarm
TA: Tamper Output
46
5. Advanced Settings
[ 2 to 5 ]
[ 1 to 10 ]
AR: Anti-Rotation
DM: Device Monitoring
SO: Soiling
TR: Device Trouble
