ONVIF motion alarm
A1 B1
AM AR SO DQ
TR TA DM
Save
HTTP notice
Device None
Scheme HTTP
IP address 192.168.0.1
80
HTTP port
User name
Password
Transmission
interval (msec.) 500
Communication
timeout (s) * 2
MO A1 B1 DQ AR AM TR SO TA DM
Use HTTP notice
Virtual input number 1
Activate
Inactivate
* = Ver.3.0 or later
?
4-2-8. ONVIF motion alarm
Can set the ONVIF motion alarm responding
to the select events.
Select events
[ A1, A11, A12, A21, A22, B1, B11, B12, B21, B22,
AM, AR, SO, DQ, TR, TA, DM ]
Respond when the selected event occurs.
-> See "4-2-5. Output terminals"
for R.E.C (REDSCAN event code)
4-2-9. HTTP notice
A function to control external devices using HTTP
based on R.E.C (REDSCAN event code).
AXIS devices controlled by Virtual Inputs and Generic
devices controlled by HTTP commands can be used.
?
Device [ None, AXIS device, Generic device,
AXIS camera
Scheme [ HTTP, HTTPS ]
IP address
HTTP/HTTPS port
User name
Password
Transmission interval (msec.)
Communication timeout (s)
Validate server certificate
Event setting
Can be set for each selected event.
Use HTTP notice
Virtual input number
Activation URI
Inactivate
Triger name
Activate:
Inactivate:
Inactivate all:
*1 = AXIS device only.
*2 = Generic device only.
*3 = AXIS camera station only.
27
station* ]
( * = Ver.3.0 or later )
[ 500 to 10,000
[ 2 to 10 ]
HTTPS only
[ 1 to 32 ] *1
*2
*2
*3
Test output.
Stops test output.
Stops all test outputs.
4. Settings
( = 10 s) ]
* Ver.3.0 or later
*2*3
