Goodrive880 Series Water-Cooled Drive Hardware Manual

2.10.2 DC fuse

A DC fuse protects the rectifier unit and DC bus in case of short circuit, avoiding thermal overload. The same
brand replacement principle should be followed. See the following table for selection.
Unit model
GD880-51-0410-6-LC
GD880-51-0530-6-LC
GD880-51-0600-6-LC
GD880-51-0650-6-LC
GD880-61-2000-6-LC

2.10.3 Isolation switch

An isolation switch acts as an isolator for the circuit, causing an obvious break in the circuit and ensuring
work safety during inspection or maintenance. The same brand replacement principle should be followed.
See the following table for selection.
Unit model
GD880-51-0410-6-LC
GD880-51-0530-6-LC
GD880-51-0600-6-LC
GD880-51-0650-6-LC
GD880-51-0410-6-LC*2
GD880-51-0530-6-LC*2
GD880-51-0600-6-LC*2
GD880-51-0650-6-LC*2
202212 (V1.0)
Frame size Voltage (V)
A8LC 1250
A8LC 1250
A8LC 1250
A8LC 1250
D3T 1250
Frame size Voltage (V)
A8LC 1000
A8LC 1000
A8LC 1000
A8LC 1000
A8LC*2 1000
A8LC*2 1000
A8LC*2 1000
A8LC*2 1000
Current (A) Model
800 170M6546
900 170M6547
1000 170M6548
1100 170M6549
2500 170M7595
Current (A) Model
1000 OT1000E11P
1000 OT1000E11P
1000 OT1000E11P
1000 OT1000E11P
1000 OT1000E22P
1000 OT1000E22P
1000 OT1000E22P
1000 OT1000E22P
Product overview
Qty
2
2
2
2
4
Qty
1
1
1
1
1
1
1
1
18
