Goodrive880 Series Water-Cooled Drive Hardware Manual
No.
push-out.)
Removed the auxiliary rope for mounting, and ensured that
6
the unit was pushed into place.
Inserted screws into the fixing holes at the unit front top and
7
bottom to fix the unit to the cabinet.
8 Checked the screw tightening state.
202212 (V1.0)
Operation
Mechanical installation
Compliant Completed
□ □
□ □
□ □
36
