Goodrive880 Series Water-Cooled Drive Hardware Manual
3.3.5.4 Layout and installation of water-cooled rectifier cabinet
Figure 3-12 shows the recommended cabinet layout of the water-cooled rectifier unit.
Control box
Cabinet
Fu se
Ou tpu t copp er
bar
202212 (V1.0)
Figure 3-12 Layout of 400mm-wide cabinet
Front-door air outlet
Fo rnt doo r
Inverter door
Front-door air inlet
（
）
+
bus
（
）
-
bus
W ate r inlet and
outlet pipes
Mechanical installation
30
