Goodrive880 Series Water-Cooled Drive Hardware Manual
Water inlet connector
(M22X1.5 metric external thread
24-degree inner cone）
202212 (V1.0)
Figure B-2 Installation dimensions of water-cooled rectifier unit
580
540
80
160
240
320
400
525
Figure B-3 Installation dimensions of water-cooled VFD unit
Fixing screw 4-M8
Water outlet connector
(M22X1.5 metric external thread
24-degree inner cone)
Dimension drawings
62
