REVEAL® FREE STANDING REFRIGERATED SELF-SERVICE MODEL APPLICABILITY & DIMENSIONS
Model
NR3633RSSV
NR3640RSSV
NR3647RSSV
NR3647RSSV2*
NR3655RSSV
NR4833RSSV
NR4840RSSV
NR4847RSSV
NR4847RSSV2*
NR4855RSSV
NR6033RSSV
NR6040RSSV
NR6047RSSV
NR6055RSSV
NR7233RSSV
NR7240RSSV
NR7247RSSV
NR7255RSSV
*V2 Models = Dual Access Models. See Cover Sheet For Dual Access Merchandiser Illustration.
Upper Display
Overall Height
Height
13 5/8"UDH
20 3/8"UDH
27 7/8"UDH
27 7/8"UDH
35 1/4"UDH
13 5/8"UDH
20 3/8"UDH
27 7/8"UDH
27 7/8"UDH
35 1/4"UDH
13 5/5"UDH
20 3/8"UDH
27 7/8"UDH
35 1/4"UDH
13 5/8"UDH
20 3/8"UDH
27 7/8"UDH
35 1/4"UDH
32 7/8"OH
39 5/8"OH
47 1/8"OH
51 1/8"OH
54 5/8"OH
32 7/8"OH
39 5/8"
47 1/8"OH
51 1/8"OH
54 5/8"OH
32 7/8"OH
39 5/8"OH
47 1/8"OH
54 5/8"OH
32 7/8"OH
39 5/8"OH
47 1/8"OH
54 5/8"OH
3
Case Depth x Length
33"D x 35 3/4"L
33"D x 35 3/4"L
33"D x 35 3/4"L
33"D x 35 3/4"L
33"D x 35 3/4"L
33"D x 47 3/4"L
33"D x 47 3/4"L
33"D x 47 3/4"L
33"D x 47 3/4"L
33"D x 47 3/4"L
33"D x 59 3/4"L
33"D x 59 3/4"L
33"D x 59 3/4"L
33"D x 59 3/4"L
33"D x 71 3/4"L
33"D x 71 3/4"L
33"D x 71 3/4"L
33"D x 71 3/4"L
