INSTALLATION, CONT'D: OPTIONAL ACRYLIC SECURITY COVER

17. Optional Acrylic Security Cover
Note: Illustrations reflects random model; it may not
reflect every feature or option of your case.
A. View of optional acrylic security cover with
holes for grasping (for removing and replacing),
enlarged lock/key and lower protrusion.
B. Acrylic security cover rests against upper
security cover stop.
C. Acrylic security cover's lower protrusions are to
rest in lower bracket slots (one in each bracket).
Acrylic Security Cover
Lower Protrusion
D
Upper
Security
Cover
Stop
Security
Cover
Lock/Key
D. Upper acrylic security cover must rest against upper
security cover stop. Lock at both ends of cover with
locking mechanism.
> Important! After locking in place, store keys in safe
yet accessible place.
> If removing acrylic security cover, store in safe
location away from foot traffic or work areas that could
lead to scratching or marring of acrylic surfaces.
> See CLEANING SCHEDULE (TO BE PERFORMED
BY STORE PERSONNEL) for cleaning information.
A
Acrylic
Security
Cover
12
Enlarged View of
Security Cover
Lock/Key
B
Upper
Security
Security Cover
Cover Stop
Lock/Key
C
Lower Bracket
For Acrylic
Security Cover
(Angled View)
