Stel REVOLUTION 2500 CE Instruction Manual page 31

Press the button ( HOME ) ( Fig.4,ref. 8 ) to
come back to main screen.
REMOTE CONTROL
To activate the REMOTE CONTROL press in Stick
or Mig Welding the button
( Fig.4,ref.11 )
MIG MANUAL MODE
Use the SELECT MODE button ( Fig.4,ref. 7 ) to
toggle through the menu until the LED next to MIG
MANUAL illuminates. You are now in the MIG
MANUAL welding mode.
Turn left encoder ( Fig.4,ref. 16 ) to set the wire
feed speed and turn right encoder
( Fig.4,ref. 12 ) to set the voltage.
Press the button INCH ( Fig.4,ref.8 ) to
momentarily feed welding wire at speed set without
energizing welding circuit or shielding gas valve.
Press the button PURGE to flow gas and purge air
from gun or adjust gas regulator.
These two functions are available only in MIG
MANUAL MODE.
If welding with synergic or pulse programs is
desired, press the SELECT MODE
( Fig.4,ref. 7 ) button to toggle the MIG 2T mode.
SYNERGIC / PULSED / DOUBLE
PULSED MIG
Press the button ( Fig.4,ref. 8 )
Select the Synergic Mig , Pulsed Mig or Double
Pulsed Mig function through the button
( Fig.4,ref.9 ) or the encoder( Fig.4,ref. 12 )
To activate the selected function, press the button
( Fig.4,ref. 11 )
6947800020
31
