Stel REVOLUTION 2500 CE Instruction Manual page 29

In order to access the TIG - MAIN SETTINGS
submenu, press button
the following screen appears
Here, you can select your pre-gas flow in seconds.
by turning encoder ( Fig.4,ref. 12 ) until you reach
your desired pre-gas flow duration.
In order to adjust the next value of the sequencer,
in this case t1 (slope up), press button
( Fig.4,ref.9 );
When using a remote control, the t1 value is fixed
(not adjustable).
With a momentary (arc on/off) switch, the t1
adjustment feature is available. Use button
( Fig.4,ref.9 ), to move to t2 (slope down).
(Fig.4, ref.9 ), and
Here, you can adjust the slope down duration in
seconds. Like t1 (slope up), it is very uncommon to
set slope down when using a foot pedal.
Use button ( Fig.4,ref.9 ) , to move to the final
station of the sequencer—post-gas flow .
By pressing button
deeper into the TIG - MAIN SETTINGS submenu.
The Revolution 2500 allows you to adjust TIG Hot
start in both AC and DC.
Most other TIG welding machines, and all other
high-end, brand name welding machines, feature a
hot-start function that delivers a factory pre-set
amount of hot-start, for a predetermined amount of
time (typically in the range of several dozen or
several hundred milliseconds).
6947800020
( Fig.4,ref.9 ); you get
29
