Stel REVOLUTION 2500 CE Instruction Manual page 26

3) To activate the selected function, press the
button (Fig. 4,ref .11)
4) Then you will go to a new screen:
6) To activate the selected function, press the
button (Fig.4, ref. 11, Pg 10)
6a) If the pulse is activated, the main screen will
look like this:
7) If the EASY SET function was previously
selected, the display will show the following screen
8) Select the type of electrode through the button
( Fig.4 ,ref. 11 ) or the encoder
( Fig.4, ref.12 );
9) To confirm the choice, press the button
( Fig.4,ref. 11 )
10) At this point we move on to the choice of the
electrode diameter
12) Select the size of the electrode through the
button ( Fig.4 ,ref. 11 ) or the encoder
( Fig.4,ref.12 ) ;
13) To confirm the choice, press the button
( Fig.4, ref. 11 )
HOT START / ARC FORCE ADJUSTMENT
14) To enter in the Arc Force / Hot Start adjustment
menu, press the button
15) To select Arc Force or Hot Start press the
button ( Fig.4,ref. 9 )
16) To change the Arc Force or Hot start value
move the encoder ( Fig.4,ref. 12 ) ;
PULSE PARAMETERS ADJUSTMENT
in MANUAL MODE )
6947800020
(Fig.4, ref. 9 ) ;
( Only
26
