TEST WAVEFORM AND VOLTAGE SETUPS
WAVEFORM MEASUREMENTS
On the left-hand pages preceding the schematic
diagrams are test waveform illustrations that are in-
tended to aid in troubleshooting the instrument. To test
the instrument for these waveforms, make the initial con-
trol settings as follows:
Vertical (Both Channels)
POSITION
U)
t-
MODE
U)=
BW LIMIT
z*
INVERT
Q :
t w
VOLTS/DIV
a t -
Z Z
VOLTS/DIV Variable
gz
lnput Coupling
n z
Horizontal
POSITION
MODE
iika
A and B SECIDIV
SECIDIV Variable
XI0 Magnifier
B DELAY TIME POSITION
B TRIGGER
SLOPE
LEVEL
Midrange
CH
1
Off (button out)
Off (button out)
0.5 V
CAL detent
GND
Midrange
A
0.5 ms
CAL detent
Off (knob in)
0.5 ms
Positive (button out)
Midrange
VAR HOLDOFF NORM
Mode P-P AUTO
SLOPE Positive (button out)
LEVEL Midrange
A & B SOURCE
VERT MODE
A COLlPL NORM
Changes to the control settings for specific wave-
forms are noted at the beginning of each set of wave-
forms. lnput signals and hookups required are also indi-
cated, if needed, for each set of waveforms.
DC VOLTAGE MEASUREMENTS
Typical voltage measurements, located on the schemat-
ic diagram, were obtained with the instrument operating
under the conditions specified in the Waveforms Mea-
surements setup. Control-setting changes required for
specific voltages are indicated on each waveforms
page. Measurements are referenced to chassis ground
with the exception of the preregulator and inverter volt-
ages on Diagram 9. 'These voltages are referenced as in-
dicated on the schematic diagram.
RECOMMENDED 'TEST EQUIPTMENT
Test equipment in Table
4-1
in the "Performance
Check Procedure", Section
4,
of this manual, meets the
required specifications for testing this instrument.
