DEMO MANUAL DC2603A-B
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 4 CIN2, CIN3, CIN4, CIN5
3 6 COUT2, COUT6, COUT13,
COUT14, COUT15, COUT16
4 4 COUT3, COUT4, COUT5, COUT8
5 1 C1
6 1 C2
7 2 C5, C7
8 2 C9, C6
9 1 C10
10 1 C12
11 4 C13, C14, C15, C16
12 1 C17
13 1 C18
14 4 R1, R3, R22, R26
15 1 R5
16 4 R9, R12, R15, R18
17 2 R10, R13
18 1 R19
19 3 R24, R27, R36
20 1 R25
21 1 R30
22 1 R37
23 2 R46, R47
24 1 U1
Additional Demo Board Circuit Components
1 0 COUT1, COUT7, COUT9,
COUT10, COUT11, COUT12,
COUT17, COUT18
2 0 C3,C4,C8,C11
3 0 R2, R4, R6, R8, R11, R14, R16,
R17, R20, R23, R28, R31, R33,
R39, R40, R41, R42, R48
4 4 R7, R21, R29, R32
5 1 R34
6 0 R35
7 0 R38, R43, R44, R45
8
PART DESCRIPTION
CAP ., 330µF, ALUM, OS-CON, 25V, 20%, SMD
10mm × 12.6mm, F12, SVPF Series
CAP ., 22µF, X5R, 25V, 10%,1210
CAP ., X5R, 330µF, 4V, 20%,1210
CAP ., 100µF, X5R, 6.3V, 20%, 1210
CAP ., 4.7µF, X5R, 16V,20%, 0805
CAP ., 1µF, X7R, 25V,10%, 0805
CAP ., 0.1µF, X5R, 25V, 10%, 0603
Cap, 33pF, C0G, 50V, 5%, 0603
CAP ., 220pF, X7R, 100V,10%, 0603
CAP ., 47pF, X7R, 50V, 10%, 0603
CAP ., 1µF, X7R, 10V,10%, 0603
CAP ., 3300pF, X7R, 50V,10%, 0603
CAP ., 4700pF, X7R, 50V,10%, 0603
RES., 10Ω, 1/10W, 1%, 0603
RES., 100k, 1/10W, 1%, 0603
RES.., 60.4k, 1/10W,1%, 0603
RES.., 6.04k, 1/10W,1%, 0603
RES., 13.3k, 1/10W,1%, 0603
RES., 10k, 1/10W,1%, 0603
RES., 40.2k, 1/10W,1%, 0603
RES., 147k, 1/10W,1%, 0603
RES., HIGH POWER, 0.01Ω, 2W,1%, 2512
RES., 10k, 1/10W,1%, 0603
I.C., 16 × 16 × 5.01 BGA
CAP ., OPT, 7343
CAP ., OPTION, 0603
RES., OPTION, 0603
RES., 0Ω, 1/10W, 0603
RES., 0Ω, 3/4W, 2010
RES., OPTION, 2010
RES., OPTION, 2512
MANUFACTURER/PART NUMBER
PANASONIC, 25SVPF330M
MURATA, GRM32ER61E226KE15L
MURATA, GRM32ER60G337ME05L
AVX, 12106D107MAT2A
KEMET, C0805C475M4PACTU
AVX, 08053C105KAT2A
AVX, 06033D104KAT2A
AVX, 06035A330JAT2A
AVX, 06031C221KAT2A
AVX, 06035C470KAT2A
AVX, 0603ZC105KAT2A
AVX, 06035C332KAT2A
AVX, 06035C472KAT2A
VISHAY, CRCW060310R0FKEA
VISHAY,CRCW0603100KFKEA
VISHAY, CRCW060360K4FKEA
VISHAY, CRCW06036K04FKEA
VISHAY, CRCW060313K3FKEA
VISHAY, CRCW060310K0FKEA
VISHAY,CRCW060340K2FKDA
VISHAY,CRCW0603147KFKEA
VISHAY, WSL2512R0100FEA18
VISHAY, CRCW060310K0FKEA
Linear Tech, LTM4650AEY-1#PBF
OPT
OPT
OPT
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW20100000Z0EF
OPT
OPT
