Client SIMATIC IPC RC-545A
SIMATIC
Industrial PC
Client SIMATIC IPC RC-545A
Operating Instructions
03/2024
A5E53092314-AA
Preface
Product description
Safety instructions
Mounting the device
Connecting the device
Commissioning the device
Operating the device
Expanding and assigning
parameters to the device
Device maintenance and
repair
Technical specifications
Dimension drawings
Standards and approvals
Hardware description
Technical support
Markings and symbols
1
2
3
4
5
6
7
8
9
10
11
A
B
C

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC IPC RC-545A

Summary of Contents for Siemens SIMATIC IPC RC-545A

  • Page 1 Client SIMATIC IPC RC-545A Preface Product description SIMATIC Safety instructions Mounting the device Industrial PC Client SIMATIC IPC RC-545A Connecting the device Commissioning the device Operating Instructions Operating the device Expanding and assigning parameters to the device Device maintenance and...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    • Service and maintenance of industrial PCs General knowledge in the field automation control engineering is recommended. Range of validity of these operating instructions These operating instructions are valid for all order variants of the SIMATIC IPC RC-545A. History Currently released versions of these operating instructions:...
  • Page 4 Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.

  • Page 5: Table Of Contents

    Safety instructions on transport and storage ............... 42 Safety instructions for assembly ..................44 Safety instructions on ambient and environmental conditions ..........46 Safety instructions for I/O devices ..................48 Safety instructions on device and system extensions ............50 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 6 Open the device ........................ 77 Installing and removing expansion cards ................78 7.2.1 Information on using expansion cards ................78 7.2.2 Installing expansion cards ....................78 7.2.3 Removing expansion cards ....................80 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 7 Installing the operating system, software, and driver ............126 8.4.1 Restoring the operating system and partitions with the SIMATIC IPC USB flash drive ..126 8.4.2 Installing software and drivers..................126 Configuring firmware/BIOS ....................127 Recycling and disposal ..................... 127 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 8 11.1.5 FCC Rules (USA) ....................... 148 11.1.6 ICES Compliance (Canada) ....................149 11.1.7 RCM (Australia / New Zealand) ..................149 11.1.8 Eurasion Customs Union EAC ................... 149 11.1.9 KC Mark (Korea)....................... 149 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 9 Markings and symbols ........................163 Overview ......................... 163 Symbols for safe use and disposal ..................163 Symbols for operator controls ..................163 Symbols of certificates and approvals ................164 Interface icons ......................... 165 Index ..............................166 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 10: Product Description

    Supplied in printed form with the device • Link and QR code to the online form for • Supplied data storage medium the quality control notification in the SIEMENS After Sales Information System (ASIS) • Operating instructions of the device • Installation of the device •...
  • Page 11 SIMATIC IPC Creating a bootable USB flash • Creating a bootable USB flash drive for drive recovery of operating system, software (https://support.industry.siemens.com/cs/ and drivers ww/en/view/109811224) SIMATIC NET Industrial communication • Online at: SIMATIC NET (http://w3.siemens.com/mcms/automatio n/en/industrielle- kommunikation/Seiten/Default.aspx) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 12: Product Highlights

    1.2 Product highlights Product highlights The SIMATIC IPC RC-545A is a client-class industrial PC in 19" rack format (4 U). It is perfectly suited for high-performance industrial PC applications. SIMATIC IPC RC-545A is available with two enclosure variants: Standard enclosure or short enclosure.
  • Page 13 • A secured internal USB slot in the device, for a software dongle, for example • Service-friendly device configuration (modifications, service), e.g. installation of drives, replacement of filter or front fan without tools Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 14: Area Of Application

    • Fast restoration of the delivery state by restoring from USB stick Area of application The SIMATIC IPC RC-545A offers system integrators, control cabinet builders, plant constructors, and machine manufacturers a 19" rack PC platform for high-performance applications and IT applications at the control and cell level for: •...

  • Page 15: External Design Of The Device

    Fan cover on front fan with openings to ventilate the device (locked with front door) ③ System status displays (Page 28) ④ Front door: lockable, protection against unauthorized access ⑤ Lock • Key vertical: open • Key horizontal: closed Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 16 Drive cage (in this case type A); depending on the expansion variant, see: • Drive cage (Page 17) ⑤ Interfaces on the front of the device, see Device ports (Page 23) ⑥ Front fan support Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 17: Drive Cage

    Slot 3 (5.25" slot) for: • 2.5" drive or 3.5" drive in the 5.25" mounting frame with removable tray • 5.25" drive or 5.25" component 5.25" mounting frame with removable tray Cover Cover Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 18 Product description 1.4 External design of the device Components of the removable tray Status display (Page 31) Status display (Page 31) Number of the mounting location (here: Mounting location 0) Lock Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 19: Drive Cage Type B

    2.5" drive in the assembly kit for 5.25" tray • 3.5" drive in the assembly kit for 5.25" tray • 5.25" drive or 5.25" component Cover (if no drive is installed) drive cover (if drive is installed) Cover Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 20: Drive Cage Type C

    2.5" drive on the drive bay plate • 3.5" drive on drive bay plate ② Six screws for attaching or loosening the drive bay plate with attached design cover (with TORX T10 screwdriver) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 21 1.4 External design of the device Slot numbering on the drive bay plate Mounting location 0 Mounting location 1 See also Installation options for drives with drive cage type C (Page 94) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 22: Rear Of The Device

    Slot brackets or connections of inserted expansion cards ⑥ Fixing screws for strain relief (Page 70) ⑦ Connections on the rear of the device (Page 24) ⑧ Power supply unit 550 W (Page 25) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 23: Device Ports

    SuperSpeed backwards compatible to USB 3.0 / 2.0 / 1.1; each 900 mA / high current Sum of the currents on the USB interfaces of the device (including the internal USB interfaces) ≤ 3 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 24: Connections On The Rear Of The Device

    SuperSpeed; backwards compatible to USB 3.0 / 2.0 / 1.1; each 900 mA / high current • (X63) ⑨ USB 2.0 Type A (480 Mbps) backwards compatible to USB 1.1; 900 mA / high current • (X60) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 25: Connection Of Power Supply Unit 550 W

    "Connecting several monitors (multi-monitoring) (Page 67)". You can find information on the graphics cards under "Technical specifications of graphic (Page 136)". 1.4.4.3 Connection of power supply unit 550 W Socket for power plug Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 26: Operator Controls

    Risk of electric shock The on-off switch does not fully disconnect the device from the line voltage. You also need to observe the notes and information under "Switching off the device (Page 72)". On-off switch Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 27: On-Off Button And Reset Button

    Reset button The reset button is for the emergency when the device can no longer be operated. You can find information on the hardware reset under "Switching off the device (Page 72)" Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 28: Status Indicators

    (see also Status displays of the • No data traffic LAN ports (Page 30)) ⑤ ETHERNET 3 (no func- tion) ⑥ WATCHDOG Watchdog status Not activated (function GREEN Activated currently not Expired available) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 29 The fan on the processor heat sink is faulty • Fan on drive cage type A faulty ⑨ HDD3 Not available with this device ALARM version ⑩ HDD2 ⑪ ALARM ⑫ HDD1 ALARM HDD0 ALARM Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 30: Status Displays Of The Lan Ports

    • Data transfer active ORANGE flashing then steady • Wake on LAN from S5 mode possible LED 2 Data transmission rate • 10 Mbps ORANGE • 100 Mbps GREEN • 1000 Mbps Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 31: Status Displays On Removable Tray For Drives

    Power supply not connected • No drive installed GREEN • Device is switched on and a drive is installed ② Activity Status of the drive ORANGE • Drive is active • Drive is not active Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 32: Internal Design Of The Device

    Drive cage (here: Drive cage type A or type B) ⑥ Guide rail for long expansion cards ⑦ Motherboard ⑧ Expansion card slots ⑨ Slot brackets (numbering of expansion card slots on the enclosure) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 33: Accessories And Replacement Parts

    Accessories and replacement parts 1.6.1 Hardware accessories Accessories from Siemens are available for your device. These are not included in the scope of supply. Obtaining accessories from the SIEMENS Industry Mall You can find additional information in the online ordering system Industry Mall (https://mall.industry.siemens.com).
  • Page 34 3-pack 1 adapter 6ES7648-3AJ00-0XA0 • mDP to DP adapter 3 adapters 6ES7648-3AJ00-1XA0* Mini DisplayPort to DisplayPort Available as single-pack or 3-pack* * Included in scope of supply of NVIDIA T400 graphics cards. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 35 A ing on the front 5.25" mounting frame for 5.25" mounting frame for removable tray. A5E35804114 HDD/SSD removable tray You can use a 2.5 "or a 3.5" drive in the removable tray. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 36 B Assembly kit HDD / SSD Assembly kit with drive bay plate for the A5E38368482 internal, standard enclo- internal installation of drives (3.5 "HDD or sure, side panel 2.5" SSD) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 37: Software Accessories

    • Catalog and ordering system for Automation and Drives: Industry Mall (https://mall.industry.siemens.com). First select your Region and then navigate to the desired topic area. • Industrial automation technology portfolio: Products & Services (https://www.siemens.com/global/en/products/automation/pc-based.html) Area: "SIMATIC IPC software and accessories". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 38: Safety Instructions

    Touching these areas or components can cause death or serious physical injury. • Disconnect the control cabinet from the power supply before opening it. • Ensure that the power to the control cabinet cannot be turned on accidentally. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 39 "Switching off the device (Page 72)". • Do not touch power cables and data transmission cables during a thunderstorm. • Keep sufficient distance from electric cables, distributors, systems, etc. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 40 • Do not short-circuit the battery. • Do not reverse the polarity of the battery. • Do not heat the battery over 100 °C. • Protect the battery from direct sunlight, moisture and condensation. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 41 Validate the correct functioning of the plant to avoid functional restrictions. Use in industrial environments Note Use in an industrial environment without additional protective measures This device was designed for use in a normal industrial environment according to IEC 60721-3-3. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 42: Safety Instructions On Transport And Storage

    A damaged device has unpredictable properties and states. Death or serious injury could occur. • Avoid installing and commissioning a damaged device. • Label the damaged device and keep it locked away. Send off the device for immediate repair. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 43 • Do not expose the device to direct heat radiation from a heating device. • If condensation develops, wait approximately 12 hours or until the device is completely dry before switching it on. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 44: Safety Instructions For Assembly

    There is a risk of overheating and personal injury. Note the following instructions and information under: • "Climatic and mechanical environmental conditions (Page 132)" • "Safety instructions on ambient and environmental conditions (Page 46)" Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 45 Touching these areas or components can cause death or serious physical injury. • Disconnect the control cabinet from the power supply before opening it. • Ensure that the power to the control cabinet cannot be turned on accidentally. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 46: Safety Instructions On Ambient And Environmental Conditions

    • When the device is operated in severe environments which are subject to caustic vapors or gases, ensure sufficient clean air is provided. • Clean the enclosure surface with a damp cloth. • Make sure that no water gets inside the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 47 • Remove radiation sources from the environment of the device. • Switch off radiating devices. • Reduce the radio output of radiating devices. • Read the information on electromagnetic compatibility. • Read the information in the technical specifications. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 48: Safety Instructions For I/O Devices

    • Switch off the affected device and then insert the power plug. • Connect all cables from the system to the device and switch all components of the system to active before starting the measurement. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 49 • For control cabinet mounting: Use a central, easily accessible AC circuit breaker, especially when close to the device. • When you install the device, ensure that the power supply plug is easily accessible. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 50: Safety Instructions On Device And System Extensions

    • For control cabinet mounting: Use a central, easily accessible AC circuit breaker, especially when close to the device. • When you install the device, ensure that the power supply plug is easily accessible. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 51 Improperly carried out repairs or extensions to the device can lead to property damage or danger to the users. If you install or exchange system expansions and damage your device, the warranty becomes void. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 52 • UL approval of the device only applies when the UL-approved components are used according to their "Conditions of Acceptability". • We are not liable for functional limitations caused by the use of third-party devices or components. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 53: Mounting The Device

    You can find information on ordering Microsoft® Windows® operating systems under: Important instructions and manuals for operating the device (Page 10) or Technical specifications of the operating systems (Page 139). Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 54 Printed documents • Quick Install Guide for the device with link and QR code to the online form for quality control (quality control notification) in the SIEMENS After Sales Information System (ASIS) • Product Information "Important notes on your device"...

  • Page 55: Checking The Delivery Package

    If the contents of the package are incomplete, damaged or do not correspond to your order, you can use the After Sales Information System (ASIS) (http://www.siemens.com/asis) to provide feedback on product deliveries and repairs. Complete the online form for quality control (quality control notification).

  • Page 56: Device Identification Data

    Information on the device equipment (device-specific) ⑦ Symbols of certificates and approvals (Page 164) Symbols for safe use and disposal (Page 163) ⑧ FCC Rules (USA) (Page 148) ⑨ ICES Compliance (Canada) (Page 149) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 57 The COA label is only available for devices delivered with Microsoft® Windows® operating system installed. Example: COA label for the Microsoft® Windows® 10 operating system (the data of the product key are grayed out in the figure) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 58: Mounting The Device

    The following device bases are available from Rittal for this purpose (Rittal Type TE 7000.620, Rittal Type VR 5501.655, Rittal Type DK 5501.655). You should also observe the information of the manufacturer of the device bases. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 59 Tower Kit can be ordered as an option, see "Hardware accessories (Page 33)". More information More information can be found in the Quick Install Guide (QIG) that is enclosed with the device. See also Rittal device bases (https://www.rittal.com/de-de/product/list.action?categoryPath=/PG0001/) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 60: Securing The Device

    • Secure the device using additional measures. The fixing screws of the telescopic rails may not protrude more than 5 mm into the device. • To carry and lift the device, use the handles on the front of the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 61 The dimensions for the holes can be found here: "Dimension drawings for drill holes for telescopic rails (Page 145)". You can find detailed information on the telescopic rails here: "Technical specifications of the telescopic rails (Page 139)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 62: Connecting The Device

    Power supply cables and device plugs must bear the prescribed markings. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 63: Connection Of Equipotential Bonding Line

    • Equipotential bonding conductor with a minimum cross section of 2.5 mm Procedure 1. Make the connection for functional ground via an equipotential bonding line to the equipotential bonding rail or grounding bar of the control cabinet in which the device is installed. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 64: Connecting The Power Supply Unit 550 W

    3. Plug the power supply cable into the power outlet. 4. Switch on the device at the on-off switch (position |). 5. To prevent unintentional removal of the power plug, secure the power plug on the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 65 Connecting the device 4.3 Connecting the power supply unit 550 W 6. Remove the retaining screw ①. 7. Screw on the power plug latch ② with the fixing screw ①. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 66: Connecting I/O Devices

    1. Connect the I/O devices to the respective interfaces. Information on the position of the interfaces is available in "Device ports (Page 23)". 2. Secure the cables (Page 70) with a strain relief. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 67: Connecting Several Monitors (Multi-Monitoring)

    Connection socket on the NVIDIA T400 itor graphics interfaces graphics card DVI-D mDP1 mDP2 mDP3 (DPP1; X71) (DPP2; X72) (X70) Monitor 1 DP (Display- Port) Monitor 2 DP (Display- Port) Monitor 3 DP (Display- Port) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 68 2. On delivery the device is set for multi-monitoring. If the delivery state settings have been changed, configure the multi-monitoring function in the firmware settings, see "Installing a graphics card (Page 88)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 69: Connecting The Device To Networks

    Control level. Additional information is available under SIMATIC NET (http://w3.siemens.com/mcms/automation/en/industrielle- kommunikation/Seiten/Default.aspx). The software package and the documentation are not included in the scope of supply. More information You can find additional information on the Internet at: Technical support (https://support.industry.siemens.com) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 70: Securing The Cables

    4. Fasten the cables to the corresponding openings in the strain relief ④ using simple cable ties. Example: Cable fastened to strain relief with cable ties Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 71: Commissioning The Device

    1. Select: "Advanced > Power Management > Restore AC after Power Loss". 2. Assign the "Always on" value to the firmware setting "Restore AC after Power Loss". See also Important instructions and manuals for operating the device (Page 10) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 72: Switching Off The Device

    • Then pull out the power plug or operate the central AC circuit breaker if installed in a control cabinet. Therefore, when installing the device in a control cabinet, ensure that the AC circuit breaker is easily accessible. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 73 Hardware reset with reset button: • Press the reset button. – The device switches off and on again. Information on the position of the buttons is available under "On-off button and reset button (Page 27)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 74: Operating The Device

    To connect additional monitors to the device at the same time (multi-monitoring), you can install a graphics card. You can find information on this here: • Connecting several monitors (multi-monitoring) (Page 67) • Installing a graphics card (Page 88) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 75: Drive Configurations

    • Fan alarm is output. The operation of the fan is monitored at the following positions: • Front panel • Processor • Drive cage type A Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 76: Trusted Platform Module (Tpm)

    Activating the Trusted Platform Module You can find information on activating the Trusted Platform Module in the detailed firmware/BIOS description in "Important instructions and manuals for operating the device (Page 10)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 77: Expanding And Assigning Parameters To The Device

    1. Unplug all connecting cables. 2. Open the front panel. (Page 74) 3. Unscrew the locking screw of the enclosure cover ①. 4. Push the enclosure cover back. 5. Lift up and remove the enclosure cover. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 78: Installing And Removing Expansion Cards

    (Page 50)". • You are familiar with the Information on using expansion cards. (Page 78) • The device is fully disconnected from the mains voltage, see "Switching off the device (Page 72)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 79 ⑤ from the card retainer and install it in the opposite hole. If you are installing a low-profile expansion card, use one of the longer card holders that are shipped with the device for mounting. 9. Close the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 80: Removing Expansion Cards

    3. Disconnect all cables and the screw of the expansion card that you wish to remove. 4. Remove the expansion card from the slot. If you do not wish to install a new expansion card, install the corresponding slot bracket with the screw. 5. Close the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 81: Installing And Removing Memory Modules

    • In case of operating errors, it may be sufficient to remove one or two memory modules or to use a memory module with lower capacity so that the physical memory expansion on the motherboard and the reserved memory of the expansion card do not overlap. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 82: Installing Memory Modules

    If you install several memory modules, install them one after the other in the following order: • Memory module 1: DIMM_A1 slot • Memory module 2: DIMM_B1 slot The slots of the memory modules are labeled on the motherboard. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 83 6. To prevent tilting, press evenly on both sides of the memory module ② until the lock audibly engages. 7. Close the device. Display of a changed memory configuration A changed memory allocation is automatically recognized when the device is switched on. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 84: Removing Memory Modules

    If you remove several memory modules, remove them one after the other in the following order: • Memory module 1: DIMM_B1 slot • Memory module 2: DIMM_A1 slot The slots of the memory modules are labeled on the motherboard. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 85 To avoid tilting, pull the memory module out of the slot evenly on both sides ②. 4. Close the device. Display of a changed memory configuration A changed memory allocation is automatically recognized when the device is switched on. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 86: Connecting A Usb Stick To The Internal Interface

    You can find information on the position of the drill holes in section "Rear of the device (Page 22)". 5. Slide the bar of the retainer ③ onto the USB stick. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 87 Expanding and assigning parameters to the device 7.4 Connecting a USB stick to the internal interface 6. Fix the retainer by turning the screw ② on the guide rail. 7. Close the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 88: Installing And Removing A Graphics Card

    You can find information on this in the firmware description of the device, see "Important instructions and manuals for operating the device (Page 10)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 89 2. To open the firmware settings, press the <Del> or <Esc> button during the boot phase, when a boot message appears. 3. Select "Advanced" > "Graphics Configuration". 4. Assign the "Auto" value to the firmware setting "Primary Display". See also Service and support (Page 159) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 90: Removing A Graphics Card

    (Page 10)". Procedure 1. The graphics card is an expansion card. Remove the graphics card. Note the information under "Removing expansion cards (Page 80)". 2. Check the firmware settings. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 91: Installing And Removing Drives In Drive Cages

    3.5" drive inside on the side panel of the device (Page 113) Drive cage type A: • Mounting location 0 • Mounting location 1 • Mounting location 2 Drive cage type A: • Mounting location 3 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 92 • Mounting location 2 Drive cage type A: • Mounting location 3 • 2 x internal in the device 1 If more than 4 drives are used, an additional controller is required Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 93: Installation Options For Drives With Drive Cage Type B

    Drive cage type B: • Mounting location 0 • Mounting location 1 • Mounting location 2 2 x internal in the device If more than 4 drives are used, an additional controller is required Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 94: Installation Options For Drives With Drive Cage Type C

    • You can find information on the mounting locations under "Drive cage type C (Page 20)" • You can find information on the procedure under "Installing a 2.5" drive or 3.5" drive in drive cage type C (Page 110)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 95: Drives In The Removable Tray

    When you remove the drive while data is being written to it, you may damage the drive and destroy data. • Only take out the removable tray when the device is switched off. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 96 9. Fold the tray bracket out of the removable tray as far as it will go and slide the removable tray fully into the drive cage. Ensure that the removable tray fits tightly in the drive cage. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 97 11. Lock the removable tray with the key. Note The removable tray must always be locked to ensure reliable operation of the devices with removable trays. See also Status displays on removable tray for drives (Page 31) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 98: Removing A Backplane For Removable Tray

    1. Open the device. See the notes under "Open the device (Page 77)". 2. Pull out both plugs ①. 3. Unlatch the backplane by firmly pressing on the latches ② in the direction of the arrow and simultaneously pressing on the ejector ③. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 99: Installing A Backplane For Removable Tray

    • You are familiar with the important safety instructions under "Safety instructions on device and system extensions (Page 50)". • The device is fully disconnected from the mains voltage, see "Switching off the device (Page 72)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 100 4. On the front of the drive cage, remove the cover ③, which may be located to the right of the cover ②. 5. Remove all existing removable trays until the drive cage is freely accessible. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 101 8. Insert the cover ② into the front of the device. 9. At the backplane, connect the data cables with the corresponding interfaces on the motherboard. 10. Connect the power supply. 11. Close the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 102: Drives In 5.25" Slots Of Drive Cages

    • You are familiar with the important safety instructions under "Safety instructions on device and system extensions (Page 50)". • The device is fully disconnected from the mains voltage, see "Switching off the device (Page 72)". • Screwdriver TORX T10 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 103 The mounting rails are labeled with "L" and "R" and can be re-installed on the blanking plate in the same way if necessary. The top of the blanking plate ⑤ is also labeled. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 104 8. Make sure that the removable tray is firmly seated in the 5.25" mounting frame. 9. Close the tray bracket. 10. Lock the removable tray with the key. 11. Close the device. 12. Connect the power supply. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 105: Changing A 2.5" Or Drive 3.5" Drive In The Assembly Kit For A 5.25" Tray

    • The device is fully disconnected from the mains voltage, see "Switching off the device (Page 72)". • When replacing a 3.5" HDD: Screwdriver TORX T10 • When replacing a 2.5" SSD: Screwdriver TORX T8 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 106 5. Remove the left and right drive mounting bars ② and the drive cover③ from the drive. Note: The drive cover is labeled "L" ④ and "TOP" ⑤. The drive mounting bars are labeled "L" and "R" respectively. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 107 9. Attach the left and right drive mounting bars ② on the drive bay ⑥. 10. Slide the drive bay evenly and without tilting 3/4 (not completely) into the guide rail of the drive cage. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 108: Installing A 5.25" Drive Or 5.25" Component

    • You are familiar with the important safety instructions under "Safety instructions on device and system extensions (Page 50)". • The device is fully disconnected from the mains voltage, see "Switching off the device (Page 72)". • Screwdriver TORX T10 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 109 5. Slide the new drive with the drive mounting bars evenly backwards into the guide rails of the drive cage and without tilting, until it clicks into place. 6. Close the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 110: Installing Drives With Drive Cage Type C

    (Page 20)") while holding the drive bay plate from the inside so that it does not fall into the device when loosened. 3. Inside the device, remove the drive bay plate with the attached design cover. 4. Remove the design cover from the front of the drive bay plate. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 111 5. Mount one or more drives on the rear of the drive bay plate. Note the holes: 3.5" HDDs: Holes on the front of the drive bay plate and on the HDDs 2.5" SSDs: Holes on the front of the drive bay plate and on the SSDs Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 112 6. Mount the design cover back onto the drive bay plate. 7. Connect the data cables to the desired connector on the motherboard and on the drive. 8. Close the device. 9. Connect the power supply. See also Hardware accessories (Page 33) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 113: Installing And Removing Drives In The Device (Only Possible With Standard Enclosure)

    1. Open the device. See the notes under "Open the device (Page 77)". 2. Screw the drive to the drive bay plate (available as option, not included in scope of delivery) at the marked holes. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 114 ③. 4. Connect the SATA cables to the SATA connectors of the motherboard (Page 151) and to the drive (③). 5. Close the device. 6. Connect the power supply unit. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 115: Device Maintenance And Repair

    Component Replacement interval Drives 3 years Backup battery 5 years 3 years Filter mat of the fan (front fan) Depending on the degree of soiling Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 116: Removing And Installing Hardware

    2. Remove the filter mat from the fan cover. 3. Insert the new filter mat loosely into the fan cover. Place the filter mat evenly in the fan cover. 4. Replace the fan cover. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 117: Changing The Front Fan

    3. Lift the fan support slightly upwards and remove it to the front from the front of the enclosure. 4. Put down the fan support with the openings facing down (fan is above). Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 118 7. Release the locking latches ④ on the fan support at the rear and front in turn and remove the fan from the fan support. 8. Loosen the locking latches ⑤ of the holder for the adapter plugs ⑥ and remove the holder. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 119 13. Insert the small fan cable connector ② in the larger adapter connector again. 14. Place the fan support with the new fan on the front of the device. 15. Replace the fan cover. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 120: Changing The Backup Battery

    • The device is fully disconnected from the mains voltage, see "Switching off the device (Page 72)". Procedure 1. Open the device. See the notes under "Open the device (Page 77)". 2. Remove the expansion cards, if necessary, see "Removing expansion cards (Page 80)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 121 The battery is unlocked and disengages from the socket. 4. Remove the battery from socket. 5. Insert the new battery into the socket with slight pressure and lock it into place. 6. Close the device. 7. Check the firmware settings. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 122: Replacing The Power Supply Unit 550 W

    9. Secure the power supply unit cables in the device again using cable ties. 10. Close the device. 11. Check the safe state of the device. 12. Switch on the power supply unit. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 123: Replacing The Processor

    3. Lift the release lever ④ and release the processor bracket ①. 4. Carefully lift the release lever ④ upwards. When doing so, ensure that you do not let go of the release lever. Illustration of processor socket without processor Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 124 8. Fold the processor bracket ① down again at the release lever ④ and lock the release lever so that the processor bracket is firmly closed. 9. Reinstall the processor heat sink. 10. Close the device. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 125: Replacing The Motherboard

    13. Reinsert all previously removed expansion cards into their slots. 14. Close the device. 15. Reconnect the device to the mains voltage and switch on the device. 16. Update the firmware settings to match the new motherboard version. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 126: Installing The Operating System, Software, And Driver

    (Page 10)". 3. Insert the provided USB stick into the device. 4. Run the file "START_DocuAndDrivers.CMD". The "Documentation and Drivers" suite opens. 5. Install the required components. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 127: Configuring Firmware/Bios

    Note If your device no longer boots, for example, after operating system crash during a firmware update, contact your local SIEMENS contact person. Recycling and disposal The devices described in these operating instructions can be recycled thanks to their low level of pollutants.

  • Page 128: Technical Specifications

    • > 6.3 A (with 550 W power supply unit). The tripping characteristic of the higher-level protection must take into account the starting currents of both the IPC and the other devices. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 129 Protection class I compliant with IEC 61140 Safety regulations • IEC 61010-2-201 • EN 61010-2-201 • UL 61010-2-201 • CAN/CSA C22.2 No 61010-2-201 not evaluated by UL See also Safety instructions on ambient and environmental conditions (Page 46) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 130: Current And Power Consumption And Power Supply Unit

    0.07 A 14.7 W 3 × hard disk drives SATA 0.1 A 22.0 W 1 × SSD 2.5" drive SATA 0.02 A 3.6 W Graphics card: NVIDIA T400 0.14 A 33.0 W Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 131: Technical Specifications Of The 550 W Power Supply Unit

    80% AM to IEC 61000-4-3 • 10 V; 10 kHz up to 80 MHz 80% AM to IEC 61000-4-6 Immunity to magnetic fields 30 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 132: Climatic And Mechanical Environmental Conditions

    In accordance with ISO 9001 The device must be free of any mechanical faults when disk drives are installed in the removable trays. See also Installation options for drives with drive cage type C (Page 94) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 133: Technical Specifications Of The Drives

    Slots for memory modules 2 x DIMM sockets for DDR5 4800 MHz, expandable to 64 GB Main memory 8 to 64 GB, DDR5 See also Technical specifications of the expansion card slots (Page 134) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 134: Technical Specifications Of The Expansion Card Slots

    Power loss per slot, permitted: ≤ 25 W • Open slot PCIe x16 ③ PCIE3_X16_1 • Gen. 3 • Active lanes: 2 ④ PCIE3_X4_1 PCIe x4 • Gen. 3 • Active lanes: 1 • Open slot Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 135 Rev. 2.3 • PCI bus primary PCIe bus CPU PCIe bus PCH Note In sum, the current for 3.3 V must not exceed 1.2 A. See also Layout of the motherboard (Page 151) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 136: Technical Specifications Of Graphic

    5120 × 2880 at 60 Hz; 32-bit color depth – up to 3x DVI: 1920 × 1200 at 60 Hz; 32-bit color depth – up to 3x VGA: 2048 × 1536 at 60 Hz; 32-bit color depth Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 137: Technical Specifications Of The Connections

    Connection for monitors with DVI-D connector Monitors with a DVI-D connector can also be connected to the DPP connection socket using an adapter. 24-pin (5 V; 500 mA) USB Type A USB Type A: • High-current Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 138: Technical Specifications Of The Connectors For The Power Supply Of Graphics Cards

    Connector on the wiring harness of the 550 W power supply unit 1 = +12 V 2 = +12 V 3 = +12 V 4 = GND 5 = GND 6 = GND Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 139: Technical Specifications Of The Telescopic Rails

    260 MB 260 MB 260 MB Windows System FAT32 or 40 GB 60 GB 120 GB 240 GB 300 GB 400 GB NTFS Data Data NTFS Remainder Remainder Remainder Remainder Remainder Remainder Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 140: Dimension Drawings

    Dimension drawings 10.1 Dimension drawings of the device 10.1.1 Dimension drawing of the device (standard enclosure) Note IEC60297_3_100 The system meets the requirements for 4 U according to IEC60297_3_100. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 141: Dimension Drawing Of The Device (Short Enclosure)

    Dimension drawings 10.1 Dimension drawings of the device 10.1.2 Dimension drawing of the device (short enclosure) Note IEC60297_3_100 The system meets the requirements for 4 U according to IEC60297_3_100. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 142: Dimension Drawings Of The Tower Kit

    10.2 Dimension drawings of the Tower Kit 10.2 Dimension drawings of the Tower Kit 10.2.1 Dimension drawing of the Tower Kit (standard enclosure) Front view and top view All dimensions in mm. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 143: Dimension Drawing Of The Tower Kit (Short Enclosure)

    Dimension drawings 10.2 Dimension drawings of the Tower Kit 10.2.2 Dimension drawing of the Tower Kit (short enclosure) Front view and top view All dimensions in mm. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 144: Dimension Drawing Of The Expansion Cards

    Device with short enclosure: up to 260 mm ② Height of the expansion card PCI: 106.7 mm (free space via expansion card: 38.3 mm) PCIe: 111.2 mm (free space via expansion card: 33.8 mm) Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 145: Dimension Drawings For Drill Holes For Telescopic Rails

    800 mm cabinet; TS 3659.190 or TS 3659.191 Dimensions of Heitec telescopic rails • for 600 mm cabinet; RP 3659.180 • for 800 mm cabinet; RP 3659.190 ② Dimensions of Schroff telescopic rails; Type 20110-072 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 146: Dimension Drawing For Drill Holes For Telescopic Rails (Short Enclosure)

    Dimensions of the Rittal telescopic rails Type 3659 • for 600 mm cabinet; TS 3659.180 or TS 3659.181 • for 800 mm cabinet; TS 3659.190 or TS 3659.191 ② Dimensions of Schroff telescopic rails; Type 20110-072 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 147: Standards And Approvals

    Certificates and approvals 11.1.1 ISO 9001 certificate The Siemens quality management system for our entire product creation process (development, production and sales) meets the requirements of ISO 9001. This has been certified by DQS (the German society for the certification of quality management systems).

  • Page 148: Ukca Marking

    This device complies with Part 15 of the FCC Rules. Operation is subject to the Operations following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 149: Ices Compliance (Canada)

    This product meets the requirements of Korean certification. This product satisfies the requirement of the Korean Certification (KC Mark). 이 기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며 가정 외의 지역에서 사용하는 것을 목적으로 합니다. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 150: Directives And Declarations

    2014/35/EU "Electrical equipment for use within specific voltage limits" (Low-Voltage Directive). Conformance with this standard has been verified according to EN 61010-2-201. 11.2.4 RoHS directive 2011/65/EU "Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment" (RoHS Directive). Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 151: Hardware Description

    Sum of the currents on the USB interfaces of the device (including the internal USB interface) ≤ 3 A Technical features of the motherboard Technical features of the motherboard can be found under "General technical specifications of the motherboard (Page 133)". Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 152: Expansion Cards

    PIRQ B PIRQ C PIRQ A PIRQ C PIRQ B PIRQ B INT D PIRQ D PIRQ C PIRQ D PIRQ B PIRQ D PIRQ C PIRQ C Organizational Pins Request Grant Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 153: Exclusive Pci Hardware Interrupt

    The resources can be viewed in Windows as follows: 1. Press the "Windows® key" and "R" simultaneously. 2. Enter the "msinfo32" command in the "Open" field. 3. Click "OK" to confirm. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 154: System Resources

    0000 0065 0000 0065 Motherboard resources 0000 0066 0000 0066 Microsoft ACPI-Compliant Embedded Con- troller 0000 0067 0000 0067 Motherboard resources 0000 0070 0000 0070 Motherboard resources 0000 0080 0000 0080 Motherboard resources Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 155 0000 5060 0000 507F Standard SATA AHCI Controller 0000 5080 0000 5083 Standard SATA AHCI Controller 0000 5090 0000 5097 Standard SATA AHCI Controller 0000 EFA0 0000 EFBF Intel® SMBus - 7AA3 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 156: Interrupt Assignments

    Can be deac- Audio Control- tivated X: Interrupt in APIC mode : Host PCI-IRQ A to H is assigned to IRQ 16 to 23 permanently in APIC mode. A specific assignment cannot be forced. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 157: Memory Address Assignments

    Intel® Serial IO I2C Host Controller - 7ACC 7F FFEF B000 7F FFEF BFFF Intel® GNA Scoring Accelerator module 7F FFEF C000 7F FFEF FFFF High Definition Audio Controller 7F FFF0 0000 7F FFFF FFFF High Definition Audio Controller Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 158: Assignment Of Expansion Interfaces To The Software In The Tia Portal (Cp Assignment)

    TIA Portal. Slot Designation on the motherboard TIA Portal Number on the en- closure PCIE4_X16_1 X100 PCIE3_X8_1 X101 PCIE3_X16_1 X102 PCIE3_X4_1 X103 PCIE3_X4_2 X104 PCI_1 X105 PCI_2 X106 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 159: Technical Support

    You can find additional information and support for the products described on the Internet at the following addresses: • Technical support (https://support.industry.siemens.com) • Support request form (https://www.siemens.com/supportrequest) • After Sales Information System SIMATIC IPC/PG (http://www.siemens.com/asis) • SIMATIC Documentation Collection (https://www.siemens.com/simatic-tech-doku-portal) • Your local representative (https://www.automation.siemens.com/aspa_app) • Training center (https://siemens.com/sitrain) •...

  • Page 160: Troubleshooting

    Time and/or date of the PC is 1. Open the firmware configuration menu. To do not correct this, press the <F2> key during the boot opera- tion. 2. Set the date and the time in the "Main" tab. Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 161: Problems When Booting The Device

    You can find the files and descriptions needed for GPT data storage medium is this on the supplied data storage medium. aborted with the following error message: "Status: 0xc0000225 Info: The boot selection failed because a required device is inaccessible" Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 162: Problems When Using Expansion Cards

    Different pin assignment expansion card and restart the device. If the error no longer occurs, the expansion card was the cause of the fault. Replace this with a Siemens expansion card or contact the supplier of the ex- pansion card.

  • Page 163: Markings And Symbols

    Attention ESD (Electrostatic sensitive Warning of hot surface device) Disposal information, observe the local regulations. Symbols for operator controls Symbol Meaning Symbol Meaning On-off switch, without electrical isola- tion On-off button, without electrical isola- tion Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 164: Symbols Of Certificates And Approvals

    Marking of Federal Communications Commission for the USA EFUP (Environment Friendly Use Peri- Approved for Korea od) marking for China Test mark of the Underwriters Labora- Approval for United Kingdom tories Approval for India Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 165: Interface Icons

    Line Out (Equipotential-bonding cable) DisplayPort interface Microphone input DVI port LAN interface, not approved for con- necting WAN or telephone Serial port USB 2.0 high-speed port USB 3.0 Gen 1 SuperSpeed port Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

  • Page 166: Index

    Drive cage type B, 19 RCM (Australia/New Zealand), 149 Drive cage type B Software license agreements, 147 Installation options for drives, 93 UL approval, 147 Drive cage type B maximum vibration exposure for drives, 94 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 167 Specification, 134 Front fan, 15 Maintenance interval, 115 Fan cover Acceptance, 116 Front fan, 15 Fan monitoring, 75 Fan support Front fan, 16 Fastening holes, (see: Drill holes) FCC Rules (USA), 148 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 168 Changing the drive in the removable tray, 95 KC Mark (Korea), 149 Korea KC Mark, 149 I/O addresses Korean Certification, 149 Assignment, 154 I/O devices Connecting, 66 Safety instructions, 48 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 169 Nameplate, 56 Quality control notification, 10, 55 NCQ, 133 New Zealand RCM, 149 NVIDIA T400 graphics card Radiation, 39 Technical specifications, 136 High frequency radiation, 39 RAID system Problems with booting, 161 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...
  • Page 170 For countries other than the USA and Canada, 62 USA and Canada, 62 Switching off Disconnecting the device from the mains Warranty, 50 voltage, 72 Forced shutdown, (see: Hardware reset) Hardware reset, 73 Shutting down the operating system, 72 Client SIMATIC IPC RC-545A Operating Instructions, 03/2024, A5E53092314-AA...

Table of Contents
