Definitions and Warnings
0-6
The necessary ESD protective measures are clearly shown in the following
diagram:
♦ a = Conductive floor surface
♦ b = ESD table
♦ c = ESD shoes
♦ d = ESD overall
♦ e = ESD chain
♦ f = Cubicle ground connection
d
b
e
f
c
a
Sitting
Fig. 0-1 ESD protective measures
d
f f
c
a
Standing
6SE7087-6NX84-1GA0
Operating Instructions SIMOVERT MASTERDRIVES
08.2008
b d
e
f f
c
a
Standing / Sitting
