02.99
PNU OP1 parameter name
*
: Ack.
Description
par.
H662 Timer1 Mode
*
Selection of mode for timer
0 = ON delay
1 = ON delay, output signal inverted
2 = OFF delay
3 = OFF delay, output signal inverted
4 = ON/OFF delay
5 = ON/OFF delay, output signal inverted
6 = Pulse generator with positive edge triggering
7 = Pulse generator with positive edge triggering, output signal
inverted
PNU=67E Hex; Type=O2; Normalization: 1==1; Block diag.: [35.2]
Timer 2 (output = B185)
H663 Timer2 B_Input
*
PNU=67F Hex; Type= O2; Normalization: 1==1; Block diag.: [35.3]
H664 Timer2 Time_s
PNU=680 Hex; Type=O2; Normalization: 1==0.001 s; Block diag.: [35.4]
H665 Timer2 Mode
*
PNU=681 Hex; Type=O2; Normalization: 1==1; Block diag.: [35.5]
Timer 3 (output = B186)
H666 Timer3 B_Input
*
PNU=682 Hex; Type= O2; Normalization: 1==1; Block diag.: [35.6]
H667 Timer3 Time_s
PNU=683 Hex; Type=O2; Normalization: 1==0.01 s; Block diag.: [35.7]
H668 Timer3 Mode
*
PNU=684 Hex; Type=O2; Normalization: 1==1; Block diag.: [35.7]
Timer 4 (output = B187)
H669 Timer4 B_Input
*
PNU=685 Hex; Type= O2; Normalization: 1==1; Block diag.: [35.1]
H670 Timer4 Time_s
PNU=686 Hex; Type=O2; Normalization: 1==0.01 s; Block diag.: [35.2]
H671 Timer4 Mode
*
PNU=687 Hex; Type=O2; Normalization: 1==1; Block diag.: [35.2]
Timer 5 (output = B188)
H672 Timer5 B_Input
*
PNU=688 Hex; Type= O2; Normalization: 1==1; Block diag.: [35.3]
H673 Timer5 Time_s
PNU=689 Hex; Type=O2; Normalization: 1==0.001 s; Block diag.: [35.4]
H674 Timer5 Mode
*
PNU=68A Hex; Type=O2; Normalization: 1==1; Block diag.: [35.5]
Siemens AG 6SE7087-6CX84-0BB1
T100 Technology Board Manual for Software Module MS100 "Multi-Purpose Drive"
as for H660
(time)
as for H662
as for H660
(time)
as for H662
as for H660
(time)
as for H662
as for H660
(time)
as for H662
Value range No. of
[unit] indices
Selection text Factory
setting
0 to 7 Ind: None
FS=0
ONdly Q
ONdly /Q
OFFdly Q
OFFdly /Q
ON/OFFdly Q
ON/OFFdl /Q
Monofl Q
Monofl /Q
0 to 200 Ind: None
FS=0
0.000 to 60.000 Ind: None
[s] FS=0.000
0 to 7 Ind: None
FS=0
0 to 200 Ind: None
FS=0
0.00 to 600.00 Ind: None
[s] FS=0.00
0 to 7 Ind: None
FS=0
0 to 200 Ind: None
FS=0
0.00 to 600.00 Ind: None
[s] FS=0.00
0 to 7 Ind: None
FS=0
0 to 200 Ind: None
FS=0
0.000 to 60.000 Ind: None
[s] FS=0.000
0 to 7 Ind: None
FS=0
Parameter List
Read
Write
(Access /
State)
1/UHABR
1/UHAB
F1110
1/UHABR
1/UHAB
1/UHABR
1/UHABR
1/UHABR
1/UHAB
F1170
1/UHABR
1/UHAB
1/UHABR
1/UHABR
1/UHABR
1/UHAB
F1200
1/UHABR
1/UHAB
1/UHABR
1/UHABR
1/UHABR
1/UHAB
F1290
1/UHABR
1/UHAB
1/UHABR
1/UHABR
1/UHABR
1/UHAB
4-71
